Silicone Rubber Extruder

Silicone Rubber Extruder thumbnail-1
Silicone Rubber Extruder thumbnail-2
Silicone Rubber Extruder photo-1
Silicone Rubber Extruder photo-2
US$ 15,000 - 25,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rubber Extruder
Brand Name:
baina
Contact Supplier Request Quote Chat Now
Zhejiang Baina Rubber & Plastic Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Rubber Extruder
Brand Name baina
Model Number xjw75
Voltage 380v50hz
Power(W) 37kw
Dimension(L*W*H) 1500*1200*1600
Weight 1500kgs
Certification CE ISO9001
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

75 silicon rubber Extruder ………………………1 set

.1 · Model                                XJP75×14D

2· Outlet direction:                          Right in and left out facing the device

 3· Central height of extruder:                  1070mm±20mm

4.L/D                                    14:1

5.Screw diameter                           75mm

6.Max. screw rotation speed (r/min)              65r/min

7.Capacity(kg)                              80kg/h

·8.Feeding mode:                           Active feeding with side roller

9· Speed adjustment mode:                  Variable frequency speed regulation

10· transducer:                            According to your requiements

11·motor:                               siemens motor AC 380V 3 phase 50Hz,(you can choose brand)

12· Pressure control:                     With pressure sensor, pressure protection value adjustment rage: 0-50MPa

13. Power source:                             380V50Hz3phase

14.Hard tooth-faced reductor                   (YJ200,  Nanchang Gannan company)

15.Painting:                                According to your requiements

16.Total power                               25kw
