Specifications
1) Purity: over 99.95% W2) Spec.: 4.5mg
3) Quality: Passing the SGS
FREE SAMPLES
Tungsten wire for halogen filament
This kind of tungsten wire is applied for manufaturing halogen filament,shock-resistance filament and other high temperature-resistance devices.
1) Type & Application
Type |
Application |
WB91 |
Applied for manufacturing halogen filament, shock-resistance filament and other high temperature-resistance devices |
WB61 |
Applied for manufacturing coiled-coil or triple CFL filament. |
WB31 |
Applied for manufacturing incandescent lamp and supporting wire, etc. |
2) Diameter Tolerance
Diameter (um) |
Weight (mg/200mm) |
200mm weight tolerance |
||
|
|
0 |
I |
II |
10 <d≤18 |
0.30-0.98 |
---- |
±3.0 |
±4.0 |
18 <d≤40 |
0.98-4.85 |
±2.0 |
±2.5 |
±3.0 |
40 <d≤80 |
4.85-19.39 |
±1.5 |
±2.0 |
±2.5 |
80 <d≤300 |
19.39-272.71 |
±1.0 |
±1.5 |
±2.0 |
300 <d≤350 |
272.71-371.19 |
---- |
±1.0 |
±1.5 |
REMARK
Note:
The diameter range can be custom-made as per the requirements of customers.
Products conform to HFQI-26 technical standard.
The diameter range can be custom-made as per the requirements of customers.
