Specifications
High pressure common rail test benchPackaging & Delivery
| Packaging Detail: | export wood carton |
| Delivery Detail: | 2 weeks after order confirmation |
Specifications
High Pressure Common Rail Test Bench Advantage:
DRV control rail pressure
High test precision
High import configuration
High Pressure Common Rail Diesel Test Bench
Functions:
1.Application: Bosch,Delphi,Denso,Siemens common rail injector and pump.
2.Pump test: measure feeding and return volume,pump chamber pressure,feeding pressure,check sealing performance, and functions of ZME valve.
3.Injector test: measure the injected fuel quantity & return volume under full-loaded, idling, pre-injection and Emission status.
4. Cleaning the injectors while testing.
5. Testing 4-6 oil injectors in one setup.
6. Test electronic high pressure pump VP37 and VE37.
7.Testing pump nozzle & electronic unit pump by additional programming system & adaptor.
8.User can add and edit the data by themselves.
9.Save and print the testing results & customer information.
Characteristics:
- Full-automatic operation procedure, save the time to set up the data.
- High import configuration: takes up 50% of equipment cost.
- China-made flow sensor.
- Remote control is convenient for software upgrading and after-sale service.
5. Support Multi-language.
Main technical parameters:
Power |
11kw, 15kw optional |
Oil pump rotation speed |
0-4000 rpm |
Test rang of rail pressure |
0-2000bar |
Test precision of rail pressure |
±0.6Mpa |
Test precision of flow sensor |
0.6% |
Measuring rang of flow sensor |
0.008-2L/Min |
Temperature of test oil |
40±2°C |
Filter precision of test oil |
less than 5μ |
Capacity of tank |
80L |
Dimension |
1760X830X1650MM |
Aggregate weight |
800KG |
Electricity |
380V, 50Hz, 3 phase |
