5" small Chassis LCD Monitor
1, metal case
2, A+ panel
3, wide temperature
4, industrial grade with wide temperature
5, 16.7M perfect color
6, long life to 60,000hrs non-stop running
7, CE, FCC, CCC. RoHS ISO9001
trade term:
1, Ex work, FOB, CIF, Express, By air
2, payment term: 100% deposit for sample
30%deposit and 70% balance before shipment
3, lead time: 2~14 working days for sample
14~30 working days according to the mass production quantity
PROJECT |
parameter |
|
Specification model |
LC-MS0501 |
|
PANEL SIZE |
5″ |
|
ACTIVE DISPALYAREA |
104mm(W)×76mm(H) |
|
DISPLAY MODE |
4:3 |
|
LCD TYPE |
TFT-LCD |
|
RESOLUTION |
640×480 |
|
MAX DISPLAY COLOR |
16.7M |
|
PIXEL PITCH(mm) |
0.264(H)×0.264(V) |
|
BRIGHTNESS(nits) |
400cd/m2 |
|
CONTRAST RATIO |
300:1 |
|
VIEW ANGLE |
1700/1700 |
|
RESPONSI TIME |
5ms |
|
V-FREQUENCCY |
60 |
|
Input and Output | ||
Composite video input |
1 (BNC×1) |
|
VIDEO | ||
System |
PAL/NTSC/SECAM |
|
OSD Display | ||
MENU |
Chinese/English |
|
POWER | ||
POWER INPUT |
DC12V 2A |
|
Max in operation |
=<15W |
|
Standby power loss |
<1W |
|
