Industrial Open Frame Panel pc With Optional Touch Screen(7"-98")
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Panel PC
Brand Name:
Anrecson/OEM
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Professional Type 10.4-82inch Metal Case CCTV MonitorNegotiableMOQ: 1 Piece -
22 " 46" Samsung Original Panel Transparent Lcd Touch Screen,transparent Lcd Display BoxNegotiableMOQ: 1 Piece
-
46' 47" 49" 55" 60" Samsung LG Sharp Original Panel Narrow Bezel Lcd Video WallNegotiableMOQ: 1 Piece
-
500,800,1000,1200,1500,2000 Nits Outdoor Lcd Monitor/sunlight Readable Lcd Monitor 10.4" to 98"NegotiableMOQ: 1 Piece
-
7" 8" 10.4"12.1" 15"17" 19" 21.5" 23.6"32"etc Fanless Panel PC, Industrial Touch Screen All in One PCNegotiableMOQ: 1 Piece
Products Status
Stock
Type
Panel PC
Brand Name
Anrecson/OEM
Model Number
LC-OPC0701T-4R
Place of Origin
Guangdong, China
industrial open frame panel pc with optional touch screen(7"-98")
Features
- Resistive touch screen (5-wile)
- fanless design, and Al-alloy panel, suitable for harsh industrial environment applications
- 2GB memory (DDRIII), up to 4GB memory, Storage 16GB (32GB optional)
- 4*USB/2*COM/ 1*HDMI/ 2*Rs232 Port
- 2xRJ45 (optional Wi-Fi connectivity supporting 802.11 a/b/g.)
- Color: Slivery
- Certifications: CE/FCC/RoHs/ISO:9001 2008
- OEM and ODM services
- Operating Temperature from -20 to 60℃
- industrial pc size from 7"-98"
Applications
- Information Display
- Digital Signage
- Advertising Terminal
- Service Kiosk
- Industrial Control
- Equipment Matching
- In-Home Control Device
- Smart Energy Application
- Security & Surveillance
- General Communication
- Navigation System
Specification
| Shen Zhen Anrecson Electronics Co.,Ltd | ||||||
| 7" Fanless Industrial Panel PC: LC-OPC0701T-4R | ||||||
| Item | Project | Specification | ||||
| LCD Display | Display Type/Size | Color TFT LCD/7″ | ||||
| Active Display Area (mm) | 154.08mm(W)×85.92mm(H) | |||||
| Display Mode | 16:10 | |||||
| Max Resolution | 800×480 | |||||
| Support Color | 16.7M | |||||
| Luminance(cd/m2) | 250nits | |||||
| Backlight | LED backlight | |||||
| Contrast Ratio | 500:1 | |||||
| Response Time | 10ms | |||||
| Pixel Pitch | 0.0642(H)×0.1790(V)5(H) | |||||
| Viewing Angle | 140/120(H/V) | |||||
| Processor System | Chip set | Intel N2807+NM10 | ||||
| CPU | N2807 | |||||
| Video | Intel GMA3650,640MHz | |||||
| Internal memory | DDR3(800/1066/1333MHz)Typ. 2G (Max 4G)(optional) | |||||
| Hard disk | 16GB high speed solid state disk (32GB optional) | |||||
| HDMI ports | 1xHDMI Port | |||||
| COM ports | Defaultx2 COM | |||||
| Ethernet ports | 2xRJ45 Realtek 8111E 1000 Mbps /(optional Wi-Fi connectivity supporting 802.11 a/b/g.) | |||||
| Audio | Realtek HD ALC269Q Line-In/Line-Out/Speaker out with 1W AMP Circuit |
|||||
| USB ports | Defaultx4 USB(Max x6) | |||||
| Touch Type | TouchScreen Type | Resistive(4-wire) | ||||
| TouchScreen interface | USB | |||||
| Power supply | Input Voltage | DC12V 3A | ||||
| Output Rating | Less Than 20W | |||||
| Temperature Range | Operating Temperature | -20~60℃ | ||||
| Relative Humidity | 20(%RH)~90(%RH) | |||||
Exhibition
Company Information
Shen zhen Anrecson Electronics Co.,Ltd was established in 1998, we are a worldwide leading manufacturer specialized in designing&producing touchscreen monitor, open frame monitor,industrial monitor, industrial panel pc, digital signage, cctv monitor and video wall etc
For more information, please visit our website. Thank you.
Terms&Shiping
1, Exw, FOB, CIF
2, payment term: 100% deposit for sample
30%deposit and 70% balance before shipment
3, lead time: 2~14 working days for sample
14~30 working days according to the mass
