TFT LCD Security Monitor 8"
Feature Descriptions :
1 commercial cctv with plastic case
2 original sumsang lcd panel
3 AD board is industrial grade with wide temperature from -20 to 80 degree
4 high definition, powerful color rendition and high resolution
5 specific high performance picture/color processing engine
6 high performance and programmable sharpening filters with noise coring
7 digital decipher control microprocesser
8 any customer service is available
9 with CE/RoHs/FCC/CCC certificates
Datasheet:
| Specification | |||||
| 8" LCD CCTV Monitor | |||||
| Mode Name | LC-ME0801 | ||||
| Screen Size | 8" | ||||
| Active Display Area (mm) | 166mm(W)×125.5mm(H) | ||||
| Display Mode | 4:3 | ||||
| LCD Type | TFT-LCD | ||||
| Resolution | 800×600 | ||||
| Display Color | 16.7M | ||||
| Pixel Pitch(mm) | 0.0675(W)×0.2025(H) | ||||
| Brightness(nits) | 250cd/m2 | ||||
| Contrast Ratio | 500:1 | ||||
| Viewing Angle | 140(H) /120(V) | ||||
| V-FREQUENCCY | 60Hz | ||||
| Response Time | 8ms | ||||
| Backlight | LED | ||||
| Input and output | |||||
| Composite video input | 2 (BNC×2) | ||||
| VGA input | 1 | ||||
| HDMI input | 1 | ||||
| Composite video Output | 1 (BNC×1) | ||||
| VIDEO | |||||
| System | PAL/NTSC/SECAM | ||||
| OSD display | |||||
| MENU | Chinese/English | ||||
| POWER | |||||
| Power input | DC 12V/4A | ||||
| Max in operation | <=15W (Max) | ||||
| Standby power loss | <1W | ||||
COMPANY CERTIFICATES: CE, RoHs, FCC, CCC, ISO 9001
After-sale Service
Anrecson product’s warranty time is one and a half year(LCD panel and high brightness product is 1 year).
DOA: If any product has quality problem, excluding damages caused by natural disasters or by human factors, we will give you
unconditional replacement within 30 days from the day you receive it. Anrecson will undertake all transportation expense for this
replacement.
RMA: Beyond the above mentioned 30 days but within the one and half years of guarantee time, if any product has quality problem,
excluding damages caused by natural disasters or by human factors, we will undertake half of transportation fee, that is, the customer
will pay the transportation fee for the goods back to Anrecson and Anrecson for the goods back to the customer.
Paid Maintenance: Beyond the warranty time of one and a half years, if any product is in malfunction and needs repairing, the customer
should pay reasonable fee for the repairment service according to the established price list of maintenance and undertake all the transportation
fee in the process of repairment. After customer’s agreement, we will immediately provide our service for the customer.
