1. Any size ranging from 5" to 82", such as 5”,7", 8", 10.4", 12.1", 15", 17", 19", 20", 21.5", 22", 24", 26", 32", 37", 40", 42", 46", 55", 65",70”,82” etc.
2. Optional touchscreen: 4-wire/5-wire Resistive,Infrared,SAW, Capacitive, with USB or RS232 touchscreen interface.
3. One aluminum bezel on the front, VESA mount and rack mount together, open frame style, embedded style, and Panel PC available, with VGA, HDMI, DVI port together, special interface such as BNC, SDI, s-video available.
4. SAMSUNG/AUO/SHARP panel, with high brightness, short response time, low power consumption; 7"-10.4" is with LED as backlight, 12"-20' CCFL, 22"-65" LED; We can also provide high brightness lcd monitor such as 1000nit,1500nit,which can be readable in sunlight, waterproof with IP 65 is also available.
5. A/D board is industrial grade with wide operating temperature, can be applied to special conditions, suitable for work 24 hours per day, 7 days per week.
6. Applicable to ATM, kiosk, transportation, automatic vending machine, POS, gaming machine, medical device, etc, industrial areas.
Anrecson profile:
Shen Zhen Anrecson Electronics Co., Ltd., a leading LCD monitor manufacturer, has been specializing in research & design and providing LCD monitors since 1998. We are based in Shenzhen with sales office all over China. Our products cover industrial lcd monitor, open frame lcd monitor, touch monitor, commercial monitor, CCTV monitor, Panel PC, video wall etc.
"ANRECSON " has been ranked in the Top 10 LCD monitor supplier with high reputation in China. Our professional R&D department with full experience can provide our customers with customized service.
"ANRECSON " products have got CE, RoHS, FCC, CCC certificates. We'll continue trying our best to give each customer our best service under the guide-line of "best quality with best price and fastest delivery". So you can rest assured to cooperate with us.
| Mode Name | LC-MI1701RT-5R |
| Screen Size | 17" |
| Active Display Area (mm) | 337.92mm(W)×270.336mm(H) |
| Display Mode | 4:3 |
| LCD Type | TFT-LCD |
| Resolution | 1280×1024 |
| Display Color | 16.7M |
| Pixel Pitch(mm) | 0.264(H)×0.264(V) |
| Brightness(nits) | 250nit |
| Contrast Ratio | 1000:1 |
| Viewing Angle | 170(H) /160(V) |
| Response Time | 4ms |
| Backlight | 2 CCFL |
| Interface | D-Sub15 pin(VGA),HDMI |
| Optional interface | DVI,BNC |
| Power | DC12V 4A 50HZ/60HZ/70HZ |
| Power Consumption | less than 25W (Max) |
| Plug & Play | DDC 1/2B |
| OSD Control | Auto adjust, Brightness, Contrast, Hori. / Vert. Position, Clock, phase, Color, Language.. |
| MENU | Chinese/English(other languages supported) |
| Mount Method | |
| Mounting | Rack Mounted |
| Optional Mounting Way | VESA 75mm/100mm |
| Touch Type | |
| TouchScreen Type | Resistive(4-wire/5-wire) |
| Optional TouchScreen Type | SAW, IR ,Capacitive |
| TouchScreen interface | Serial (RS232) or USB(B) |
| Dimension(W×H×T) | depend on request |
| Certificate Approval | CE,RoHS,CCC,FCC,ISO9000(optional UL) |
| Warranty | 1.5 years |
| Application | |
| ATM/ Kiosk/Transportation/ Industrial Automation/Medical Treatment | |
