LED backlight 8" industrial Panel PC IP65 all in one for industrial devices
Features:
1. Any size from 7" to 82"", such as 7", 8", 10.4", 12.1", 15", 17", 19", 20", 21.5", 22", 24", 26", 32", 37", 40", 42", 46", 55", 65",70",82", etc, support any existing OS system.
2. Touch optional.
3. Applicable to ATM, Self-service Kiosk, Digital Signage, Gaming, POS, Medical Treatment, Media Player and other industrial control area.
4. Waterproof, dust proof, vandal proof available.
5. Fanless Panel PC, high brightness Panel PC(sunlight viewable), waterproof Panel PC IP65, medical Panel PC, open frame monitor, industrial monitor, touch monitor, CCTV monitor, advertising machine, medical monitor, transparent lcd monitor, video wall available.
6. Any OEM product is available. OEM & ODM service is offered.
| Item | Project | Parameter | ||||
| LCD Display | Display Type/Size | Color TFT LCD/8″ | ||||
| Active Display Area (mm) | 163.6mm(W)×123mm(H) | |||||
| Display Mode | 4:3 | |||||
| Max Resolution | 800×600 | |||||
| Support Color | 16.7M | |||||
| Luminance(cd/m2) | 250nit | |||||
| Backlight | LED backlight | |||||
| Contrast Ratio | 500:1 | |||||
| Response Time | 7ms | |||||
| Pixel Pitch | 0.0675(W)×0.2025(H) | |||||
| Viewing Angle | 140/120(H/V) | |||||
| Processor System | Chip set | Intel Atom D525+ICH8M | ||||
| CPU | Intel core D525(optional N455/N475 CPU) | |||||
| Internal memory | DDR3(800/1066/1333MHz)Typ. 2G (Max 4G)(optional) | |||||
| Hard disk | 16GB high speed solid state hard disk (optional) | |||||
| VGA ports | 1xVGA Ports | |||||
| COM ports | Defaultx2 COM(optional) | |||||
| Ethernet ports | One Realtek 8111E 1000 Mbps /(optional Wi-Fi connectivity supporting 802.11 a/b/g.) | |||||
| Audio | with Realtek ALC662 Line-In/Line-Out/Speaker out with 3W AMP Circuit |
|||||
| USB ports | Defaultx4 USB(Max x6) | |||||
| Touch Type(optional) | TouchScreen Type | Resistive(4-wire/5-wire) | ||||
| Optional Touch Type | SAW, IR, Capacitive | |||||
| TouchScreen interface | Serial (RS232) or USB | |||||
| Power supply | Input Voltage | DC12V 3A | ||||
| Output Rating | less than 18W | |||||
| Temperature Range | Operating Temperature | -20~70°C | ||||
| Storage Temperature | -20~70°C | |||||
| Relative Humidity | 20(%RH)~90(%RH) | |||||
1. Payment term: 100% deposit for sample, 30% deposit and 70% balance before shipment, or western union.
2. Lead time: 1~10 working days for sample, 14-30 working days for mass production, according to the quantity.
3. Shipping port: Shenzhen or HongKong, by DHL, FEDEX, EMS, UPS, TNT, depend on the customer.
4. MOQ: 1 pc, any sample order is welcome for testing our quality.
| Remarks: | |||||
| 1. The price is based on USD currency and EXW terms. | |||||
| 2. Payment Terms: 100%T/T in advance for sample; 30% T/T deposit, 70% T/T before shipping for bulk order. | |||||
| 3. Delivery Time: 3-7 workdays for sample, 15-25 workdays for bulk order. | |||||
| 4. Warranty: 18 months | |||||
| 5. Certificates: CE, RoHS, FCC, CCC, ISO | |||||
