industrial Panel PC 8"
Features:
1. Any size from 7" to 82"", such as 7", 8", 10.4", 12.1", 15", 17", 19", 20", 21.5", 22", 24", 26", 32", 37", 40", 42", 46", 55", 65",70",82", etc, support any existing OS system.
2. Touch optional.
3. Applicable to ATM, Self-service Kiosk, Digital Signage, Gaming, POS, Medical Treatment, Media Player and other industrial control area.
4. Waterproof, dust proof, vandal proof available.
5. Fanless Panel PC, high brightness Panel PC(sunlight viewable), waterproof Panel PC IP65, medical Panel PC, open frame monitor, industrial monitor, touch monitor, CCTV monitor, advertising machine, medical monitor, transparent lcd monitor, video wall available.
6. Any OEM product is available. OEM & ODM service is offered.
| Item | Project | Parameter | ||||
| LCD Display | Display Type/Size | Color TFT LCD/8″ | ||||
| Active Display Area (mm) | 163.6mm(W)×123mm(H) | |||||
| Display Mode | 4:3 | |||||
| Max Resolution | 800×600 | |||||
| Support Color | 16.7M | |||||
| Luminance(cd/m2) | 250nit | |||||
| Backlight | LED backlight | |||||
| Contrast Ratio | 500:1 | |||||
| Response Time | 7ms | |||||
| Pixel Pitch | 0.0675(W)×0.2025(H) | |||||
| Viewing Angle | 140/120(H/V) | |||||
| Processor System | Chip set | Intel j1900 | ||||
| CPU | J1900/N2807 | |||||
| Internal memory | DDR3(800/1066/1333MHz)Typ. 2G (Max 4G)(optional) | |||||
| Hard disk | 16GB high speed solid state hard disk (optional) | |||||
| VGA ports | 1xVGA Ports | |||||
| COM ports | Defaultx2 COM(optional) | |||||
| Ethernet ports | One Realtek 8111E 1000 Mbps /(optional Wi-Fi connectivity supporting 802.11 a/b/g.) | |||||
| Audio | with Realtek ALC662 Line-In/Line-Out/Speaker out with 3W AMP Circuit |
|||||
| USB ports | Defaultx4 USB(Max x6) | |||||
| Touch Type(optional) | TouchScreen Type | Resistive(4-wire/5-wire) | ||||
| Optional Touch Type | SAW, IR, Capacitive | |||||
| TouchScreen interface | Serial (RS232) or USB | |||||
| Power supply | Input Voltage | DC12V 3A | ||||
| Output Rating | less than 18W | |||||
| Temperature Range | Operating Temperature | -20~70°C | ||||
| Storage Temperature | -20~70°C | |||||
| Relative Humidity | 20(%RH)~90(%RH) | |||||
Trade tems:
1. Payment term: 100% deposit for sample, 30% deposit and 70% balance before shipment, or western union.
2. Lead time: 1~10 working days for sample, 14-30 working days for mass production, according to the quantity.
3. Shipping port: Shenzhen or HongKong, by DHL, FEDEX, EMS, UPS, TNT, depend on the customer.
4. MOQ: 1 pc, any sample order is welcome for testing our quality.
Anrecson profile:
Shen Zhen Anrecson Electronics Co., Ltd., a leading LCD monitor manufacturer, has been specializing in research & design and providing LCD monitors since 1998. We are based in Shenzhen with sales office all over China. Our products cover industrial lcd monitor, open frame lcd monitor, touch monitor, commercial monitor, CCTV monitor, Panel PC, video wall etc.
"ANRECSON " has been ranked in the Top 10 LCD monitor supplier with high reputation in China. Our professional R&D department with full experience can provide our customers with customized service.
"ANRECSON " products have got CE, RoHS, FCC, CCC certificates. We'll continue trying our best to give each customer our best service under the guide-line of "best quality with best price and fastest delivery". So you can rest assured to cooperate with us.
Wooden safe package by air, sea cargo or fast delivery air cargo
