Home > Products > Turbine Oil Purifier > 2013 Equipment for Repair Turbine Oil,TZL Turbine Oil Purification Machine
2013 Equipment for Repair Turbine Oil,TZL Turbine Oil Purification Machine
- chongqing china
- T/T Money Gram
You May Like
Product Details
| Condition | New | Type | Suction Filter | |
| Structure | Vacuum | Place of Origin | Chongqing, China | |
| Brand Name | junneng | Model Number | TZL-50 | |
| Power(W) | 42KW | Weight | 450KG | |
| Dimension(L*W*H) | 1450*950*1600 | Certification | CE | |
| Warranty | 1YEARS | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
equipment for repair turbine oil,TZL turbine oil purification machine
Widely used in electric power, metallurgy and chemical industry, to purification the turbine oil of steam turbine, turbine, fuel machine and turbine generator online.
Function:
- Machine used the latest technology at home and abroad which with strong breaking emulsion, dehydration, in addition to the ability of removal impurities.
- Sophisticated filtration system can remove all impurities effectively, using high-quality filter and long service life, pollutant carrying capacity and handling a large amount of oil which is up to 6000T or more.
- Optimization of the electrical heating temperature control system to ensure uniform heating oil, stable and no dead zone.
- Advanced infrared liquid level control system and pressure protection device which makes the machine simple used, safe and reliable.
Model | Unit | TZL-20 | TZL-30 | TZL-50 | TZL-70 | TZL-100 | TZL-150 | TZL-200 | |
Rated Flow | L/min | 20 | 30 | 50 | 70 | 100 | 150 | 200 | |
Vacuum Range | Mpa | -0.07~-0.099 | |||||||
Temperature Range | °C | 40~80 | |||||||
Oil pump pressure | Mpa | ≤0.4 | |||||||
Total Power | kw | 28 | 32 | 42 | 56 | 68 | 89 | 130 | |
Acid value | mgKOH/g | ≤0.1 | |||||||
Working Noise | db(A) | 65~85 | |||||||
Cleanliness | NAS1638 | ≤NAS 6 | |||||||
Demulsifying value | min | ≤15 | |||||||
Water content in oil | PPM | ≤40 | |||||||
Mechanical impurity | % | No | |||||||
inlet(outlet)diameter | mm | 25 | 25 | 32 | 32 | 42 | 50 | 60 | |
Dimension(mm)
| L | 1400 | 1400 | 1450 | 1500 | 1550 | 1550 | 1600 | |
W | 920 | 950 | 900 | 940 | 1000 | 1200 | 1300 | ||
H | 1420 | 1500 | 1600 | 1650 | 1700 | 1500 | 1820 | ||
If you want to know more information about these series, please contact us.
Our products include:
Series of RZL Lubricating Oil Purifier
Series of RZL-B Lubricating Oil Purifier
Series of ZLA Two-Stage Vacuum Oil Purifier
Series of ZL High-Efficient Vacuum Oil Purifier
Series of ZLC Two-Stage Multi-Function Vacuum Oil Purifier
Series of ZSC Engine Oil Purifier
Series of KL Phosphate Ester Fire-Resistant Oil Filter Machine
Series of JNC Waste Oil, Black Oil Renew to Diesel Equipment
Series of TLA Light Fuel Oil Purifier
Series of LY Plant Pressure Oil Filtering Machine
Series of JL Portable Filtering Tanker
