Turbine Oil Dehydration Filter Fuel Machine
TZL Purifier Series Solely Designed for Turbine Oil is case-hardened product of electric power industry. This machine adopts the latest techniques that integrate gravity, sedimentation, agglomeration, vacuum separation, adsorption, separation, and pressure filtration. It has super ability of demulsification, dehydration, degasification, and removing impurity, so it is the ideal equipment for disposing wheel oil, low viscidity lubricant, and hydraulic pressure.
It is widely used in electric power, metallurgy, etc. for purifying turbo oil of steam turbine, water turbine, fuel machine and steam turbine group. It can demulsify, dehydrate and purify water-mixed, serious emulsified turbo oil, and low viscidity lubricant. It can be also used in other mechanical equipment.
Technical Parameters:
| Model | Unit | TZL-30 | TZL-50 | TZL-70 | TZL-100 | TZL-150 | TZL-200 | |
| Rated Flow | L/min | 30 | 50 | 70 | 100 | 150 | 200 | |
| Vacuum Range | Mpa | -0.07~-0.099 | ||||||
| Temperature Range | °C | 40~80 | ||||||
| Oil pump pressure | Mpa | ≤0.4 | ||||||
| Total Power | kw | 22 | 28 | 48 | 68 | 86 | 102 | |
| Acid value | mgKOH/g | ≤0.1 | ||||||
| Working Noise | db(A) | 65~85 | ||||||
| Cleanliness | NAS1638 | ≤NAS 6 | ||||||
| Demulsifying value | min | ≤15 | ||||||
| Water content in oil | PPM | ≤40 | ||||||
| Mechanical impurity | % | No | ||||||
| inlet(outlet)diameter | mm | 25 | 32 | 32 | 42 | 50 | 60 | |
| Dimension(mm) | L | 1400 | 1450 | 1500 | 1550 | 1550 | 1600 | |
| W | 960 | 950 | 1000 | 1100 | 1200 | 1300 | ||
| H | 1500 | 1600 | 1650 | 1700 | 1700 | 1820 |
Dimension and weight will be changed with changing the technical specification.
More of our products:
Series of ZSC Engine Oil Purifier
Series of TLA Light Fuel Oil Purifier
Series of JL Portable-Type Oil Purifier
Series of RZL Lubricating Oil Purifier
Series of RZL-B Lubricating Oil Purifier
Series of ZLA Two-Stage Vacuum Oil Purifier
Series of ZL High-Efficient Vacuum Oil Purifier
Series of LY Plant Pressure Oil Filtering Machine
Series of ZLC Two-Stage Multi-Function Vacuum Oil Purifier
Series of KL Phosphate Ester Fire-Resistant Oil Filter Machine
Series of JNC Waste Oil, Black Oil Renew to Diesel Equipment
