Chongqing ZLA-30 Used Transformer Oil Dehydration Plant
- chongqing port
- Money Gram
You May Like
-
Chongqing ZLA-150 On Site Used Transformer Oil Recycling Machine
-
ZLA-100 Full Automatic Dirty Transformer Oil Purification Plant For Dehydration
-
ZLAused Oil Purifying Machine
-
ZLA-50 Double-stage Insulating Oil Recovering Machine
-
ZLA-50 2-Stage Dielectric Oil Filter Machine
-
ZLA Used Oil Recycle Equipment
Product Details
| Condition | New | Type | Return Filter | |
| Structure | Vacuum | Place of Origin | Chongqing, China | |
| Brand Name | JunNeng | Model Number | ZLA-30 | |
| Power(W) | 38 | Weight | 350KG | |
| Dimension(L*W*H) | 2100*1600*1600 | Certification | ISO9001:2000 | |
| Warranty | 1Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Chongqing ZLA-30 Used Transformer Oil Dehydration Plant
ZLA Used Transformer Oil Dehydration Plant is manufactured as per standards which go beyond Chinese legal mandates, the super big absorptive two stage vacuum purifies all insulation oil of power equipment rapidly and in more depth which removes water, gas and impurity in the oil rapidly and effectively with the support of high vacuum and absorption speed. Thus the strength of insulation oil is much increased and the time for oil treatment is shortened.
Features:
1) Manufactured as per standards which go beyond the legal mandates, a primary breakdown voltage can raise 35KV and reduces the harm to the oil caused by normal purifiers due to repeated heating.
2) Big absorption speed double vacuum satisfies the needs of vacuum zing of transformer on an installation or repair site, and the water/gas removal of transformer oil can be completed at same time, which shortens significantly the time for oil treatment.
3) A unique gas/water removal system adopting stereo-evaporation technology, which rapidly separates the water and gas content in the oil and the system, is free of maintenance.
4) A superior purification system with top quality filter core, which can accommodate large quantity of dirt and is dandified progressively step by step. The filter core has got a high precision and multi-stage filtration.
5) Imported parts are used for all electric system, which ensures operation of the equipment with high performance.
6) An advanced infrared liquid level control system with automatic control, allowing separated operation of manual operators from a machine.
7) Purifiers are equipped with an interlocked safety protective device. I.E, backflow of A oil outlet over pressure can be achieved via an overflow valve, B oil inlet will interlock with heating system which avoids any possible negative impacts caused by mal-operation
8) Precision oil pumps for designated purpose are used, which have low noise and environmental regulatory compliance is well met
Technical Parameters
Model | Unit | ZLA-20 | ZLA-30 | ZLA-50 | ZLA-70 | ZLA-100 | ZLA-150 | ZLA-200 |
Rated flow | L/min | 20 | 30 | 50 | 70 | 100 | 150 | 200 |
Vacuum Range | Mpa | -0.05~-0.099 | ||||||
Temperature Range |
| 40~80 | ||||||
Oil pump pressure | Mpa | 0.05~0.3 | ||||||
Total Power | kw | 33 | 38 | 46 | 62 | 90 | 120 | 144 |
Power |
| 50HZ 380V | ||||||
Working Noise | db(A) | ≤6585 | ||||||
Cleanliness | NAS1638 | ≤NAS 6 | ||||||
Breakdown Voltage | kv | ≥75 | ||||||
Water content in oil | PPM | ≤3 | ||||||
Gas content in oil | % | ≤0.05 | ||||||
Filter precision | µm | ≤3 | ||||||
Inlet (outlet) diameter |
| 25 | 25 | 32 | 32 | 42 | 50 | 60 |
mm dimension | L | 1380 | 1480 | 1670 | 1820 | 2000 | 2100 | 2300 |
W | 870 | 980 | 1150 | 1300 | 1500 | 1600 | 1800 | |
H | 860 | 950 | 1000 | 1200 | 1300 | 1600 | 1600 | |
.
Dimension and weight will be changed with changing the technical specification
Except this ZLA Used Transformer Oil Dehydration Plant ,we also have other series products
Series of RZL Lubricating Oil Purifier
Series of RZL-B Lubricating Oil Purifier
Series of ZL High-Efficient Vacuum Oil Purifier
Series of TZL Turbine Oil Purifier
Series of ZLC Two-Stage Multi-Function Vacuum Oil Purifier
Series of ZSC Engine Oil Purifier
Series of KL Phosphate Ester Fire-Resistant Oil Filter Machine
Series of JNC Waste Oil, Black Oil Renew to Diesel Equipment
Series of TLA Light Fuel Oil Purifier
Series of LY Plant Pressure Oil Filtering Machine
Series of JL Portable-Type Oil Purifier
