High Density Hydrophilic Water Bio-soluble Fiber Paper

High Density Hydrophilic Water Bio-soluble Fiber Paper thumbnail-1
High Density Hydrophilic Water Bio-soluble Fiber Paper thumbnail-2
High Density Hydrophilic Water Bio-soluble Fiber Paper thumbnail-3
High Density Hydrophilic Water Bio-soluble Fiber Paper photo-1
High Density Hydrophilic Water Bio-soluble Fiber Paper photo-2
High Density Hydrophilic Water Bio-soluble Fiber Paper photo-3
US$ 1,600 - 1,683 MOQ: 1 Box
Key Specifications
Get Latest Price
Grade:
COM (Common)
Application:
Refractory
Thickness:
1-5MM
Contact Supplier Request Quote Chat Now
Shandong Luyang Energy-Saving Materials Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Grade COM (Common)
Application Refractory
Thickness 1-5MM
Width 600-1220mm(600,610,1000,1200,1220)
Length 60000mm ---10000mm
Chemical Composition Al2O3
Working Temperature 1000/1100
Fiber Diameter 3.5um
Shrinkage (1800 ℉, 3h) 3 (hours)
Thermal Conductivity 0.124-0.202
Model Number LYKX-1260RZ
Brand Name LUYANGWOOL
Place of Origin Shandong, China
  • LUYANGWOOL® bio-soluble fiber paper is a lightweight refractory material processed form soluble fibers into a highly flexible , uniform sheet .it is recommended for continuous use at temperature up to 1000C. Soluble fiber paper has low shrinkage , good handling strength and low thermal conductivity .It contains a small amount of origanic binder which makes it flexible ,and reduces off-gassing and odour during using .

> High fired tensile strength

>Easy to cut ,wrap or form

>Temperature stability

>Low thermal conductivity

>Excellent flexibility

>Excellent flame resistance



>Replacement of asbestos paper

>Investment cast mold wrap insulation

>One-time consumable insulating applications

>Back-up lining for metal troughs

>Hot top lining

>Applications where low binder content is required

>Thermal and electrical insulation

>Upgrade for fiberglass paper and blanket





Description

    Bio-soluble Fiber Paper

Al2O3

<1.0

SiO2

57-67

CaO+MgO

30-40

K2O+Na2O

<0.2

Density (kg/m3)

200

Classification Temperature ( 0C )

1260

Linear Shrinkage after heating ( % )

1000°C*24h≤2.5

Tensile Strength (Mpa)

>0.3

40000*610/1220*1

30000*610/1220/2

20000*610/1220*3

10000*610/1220*4

Please contanct us if you want  more size !!



High density hydrophilic water bio-soluble Fiber paperHigh density hydrophilic water bio-soluble Fiber paper

High density hydrophilic water bio-soluble Fiber paper
