Ceramic Fiber Module (the Largest Manufactor in China)

Ceramic Fiber Module (the Largest Manufactor in China) thumbnail-1
Ceramic Fiber Module (the Largest Manufactor in China) photo-1
US$ 1,133 - 2,899 MOQ: 1 Ton
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
LUYANGWOOL
Model Number:
LYTX-1140MK/1260MK/1427MK
Contact Supplier Request Quote Chat Now
Shandong Luyang Energy-Saving Materials Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name LUYANGWOOL
Model Number LYTX-1140MK/1260MK/1427MK
Application refractory
Grade COM (Common)
Dimensions 300x300x200/250/300
Working Temperature 1000/1100/1350
Fiber Diameter 3.5um
Thermal Conductivity 0.09-0.175

Specifications

Ceramic Fiber Block
1.Lower heat storage
2.Installation easily
3.Density: 200-220kg/m3
4.Temperature:1140~1430C



  • LUYANGWOOL ceramic fiber module are made from LUYANG ceramic fiber blanket. These blocks are specially designed to meet or improve the thermal insulation requirements of industrial furnaces.



           Application



  • Ceramic industry~ low mass kiln cars,contiual and batch kiln,door linings,glazing,porcelain furance liners.
  • Power generation~ duct lining,heat recovery,boiler insulation,stack linings
  • Refing and petrochemical: ethylene furnace roof and wall,pyrolysis furnace lining,reformer furnace roof and wall.boiler lining.
  • Steel industry~heat treat furnace,ladle pre-heaters and covers,soaking pit covers and seals,heaters and reformer lining.
  • Others:incineration equipment,burner blocks,induction furnace covers,glass tempering furnace.

          Technical Data Sheet

  • Shringkage on heating (%)   1100CX24h ≤-3
  • Slag content ( diameter ≥0.212mm)(%): ≤20

          Standard Specification

  • Width:  300mm
  • Thickness: 200/250mm
  • Density: 220kg/m3



Description                           STD                   HP                 HZ

Chemical Composition(%)

Al2­O3                                               ≥44                     ≥45                           ≥34

SiO2                                                 ≥52                     ≥54              ≥50

Fe2O3+TiO2                                         ≤1                                   ≤0.5                     ≤0.5

ZrO2                                                   -                                                -                         ≥15

K2O+Na2O+Fe2O3                               ≤1                                   ≤0.2                     ≤0.2

Physical Properties

Density(kg/m3)avg                     220                       220                 220

Classification Temperature(°C)          1260                       1260               1430

Liner Shrinkage after heating(%)   1000°Cx24h≤2.5           1100°Cx24h≤2.5       1200°Cx24h≤3.5

Thermal Conductivity (W/m.k)

400°C                                 0.090                       0.101                 0.118

500°C                                 0.119                       0.12                 0.149

600°C                                 0.152                       0.175                 0.172



      Customized service is available. For more information,please contact us !
