- LUYANGWOOL ceramic fiber block are made from LUYANG ceramic fiber blanket. These blocks are specially designed o meet or improve the thermal insulation requirements of industrial furnaces.
Application
- Ceramic industry~ low mass kiln cars,contiual and batch kiln,door linings,glazing,porcelain furance liners.
- Power generation~ duct lining,heat recovery,boiler insulation,stack linings
- Refing and petrochemical: ethylene furnace roof and wall,pyrolysis furnace lining,reformer furnace roof and wall.boiler lining.
- Steel industry~heat treat furnace,ladle pre-heaters and covers,soaking pit covers and seals,heaters and reformer lining.
- Others:incineration equipment,burner blocks,induction furnace covers,glass tempering furnace.
Description STD HP HZ |
Chemical Composition(%) |
Al2O3 ≥44 ≥45 ≥34 |
SiO2 ≥52 ≥54 ≥50 |
Fe2O3+TiO2 ≤1 ≤0.5 ≤0.5 |
ZrO2 - - ≥15 |
K2O+Na2O+Fe2O3 ≤1 ≤0.2 ≤0.2 |
Physical Properties |
Density(kg/m3)avg 220 220 220 |
Classification Temperature(°C) 1260 1260 1430 |
Liner Shrinkage after heating(%) 1000°Cx24h≤2.5 1100°Cx24h≤2.5 1350°Cx24h≤3.5 |
Thermal Conductivity (W/m.k) |
400°C 0.090 0.101 0.118 |
500°C 0.119 0.12 0.149 |
600°C 0.152 0.175 0.172 |
Technical Data Sheet
- Shringkage on heating (%) 1100CX24h ≤-2.5
- Slag content ( diameter ≥0.212mm)(%): ≤20
Standard Specification
- Width: 300mm
- Thickness: 200/250mm
- Density: 200-220kg/m3
Customized production is also available. For more information,please contact us !
