Heat Shrinkable Cable Accessories
Negotiable
/ Set
10 Sets(Min. Order)
- NIngbo Shanghai
- T/T Money Gram
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Heag | |
| Model Number | WSY-24/3.1 |
Product Description
Specifications
heat shrinkable cable accessoriessingle core and 3 cores
indoor and outdoor
termination kits and straight through joints
| Description of goods | Specification | Size of conductor (mm2) |
| single core "XLPE" indoor termination kit | NSY-24/1.1 | 25-50mm2 |
| NSY-24/1.2 | 70-120mm2 | |
| NSY-24/1.3 | 150-240mm2 | |
| NSY-24/1.4 | 300-500mm2 | |
| single core "XLPE" outdoor termination kit | WSY-24/1.1 | 25-50mm2 |
| WSY-24/1.2 | 70-120mm2 | |
| WSY-24/1.3 | 150-240mm2 | |
| WSY-24/1.4 | 300-500mm2 | |
| single core "XLPE" straight through joint | JSY-24/1.1 | 25-50mm2 |
| JSY-24/1.2 | 70-120mm2 | |
| JSY-24/1.3 | 150-240mm2 | |
| JSY-24/1.4 | 300-500mm2 | |
| 3 cores "XLPE" indoor termination kit | NSY-24/3.1 | 25-50mm2 |
| NSY-24/3.2 | 70-120mm2 | |
| NSY-24/3.3 | 150-240mm2 | |
| NSY-24/3.4 | 300-500mm2 | |
| 3 cores "XLPE" outdoor termination kit | WSY-24/3.1 | 25-50mm2 |
| WSY-24/3.2 | 70-120mm2 | |
| WSY-24/3.3 | 150-240mm2 | |
| WSY-24/3.4 | 300-500mm2 | |
| 3 cores "XLPE" straight through joint | JSY-24/3.1 | 25-50mm2 |
| JSY-24/3.2 | 70-120mm2 | |
| JSY-24/3.3 | 150-240mm2 | |
| JSY-24/3.4 | 300-500mm2 |
| Technical Data(24KV) | |
| Property | Typical Data |
| AC withstand(under rain) | 56kv/1min |
| AC withstand(without rain) | 56kv/1min |
| Impulse withstand | ±125KV/10 times |
| DC withstand | 96KV/15min |
| AC withstand | 48KV/4h |
| Partial discharge test | 10pc(1.73Uo) |
heat shrinkable cable accessories
single core and 3 cores indoor and outdoor termination kits and straight through joints
