58mm 2inch Self-service kiosks TP-200V Thermal Printer head
- 10000 Unit / Units per Month
- Xiamen China
- Credit Card
You May Like
-
Sanor 350B barcode printer
-
Sanor 350B 80mm thermal barcode label printer
-
350B 16-82mm adjustable barcode sticker label printer
-
350B 3inch cheap barcode printer thermal label printer
-
Barcode label thermal printer thermal barcode printer with Parallel/RS232+USB/LAN
-
3inch label barcode printing machine/thermal label printing machine with RS232/USB/LAN
Product Details
Products Status | Stock | Type | Other, Thermal line printing | |
Style | Black And White | Use | Other, thermal printer head | |
Interface Type | Other | Max Paper Size | 58mm | |
Black Print Speed | 62.5mm/s | Color Print Speed | No | |
Max. Resolution | 8 dots/mm ,384 dots/lines | Brand Name | SANOR | |
Model Number | TP-200V | Place of Origin | Fujian, China |
Product Description
58mm 2inch Self-service kiosks TP-200V Thermal Printer head
Feature:
- Very silent printing thru direct thermal printing method
- Paper width:57±1mm
- Easy paper load
- Compact design
- Low Noise
- With paper detect
- Mechanism life(50KM)
- Printing width 48mm
- High speed (80mm/sec, MAX)
- Easier paper roll loading by CLAMSHELL design
Application:
- EFTs POS
- Fiscal printers
- Automotive
- Medical equipments
- Portable printers and terminals
- Hand held terminals
- Measuring Instruments and Analysers
- Data terminal devices
- Taxi meters
- Cash register
- Calculators
Specification:
Type | TP-200V | |
Print method | Thermal dot line printing | |
Resolution (dots/mm) | 8 | |
Dot per line (dots/line) | 384 | |
Speed (mm/sec) | 90(8.5VDC) | |
Print width/Paper width(mm) | 48/58 | |
Head temperature detect | Via thermistor | |
Thermal Printer head detect | Via photo interrupter | |
Paper detect | Via photo interrupter | |
Life span | Pulses | 100 million |
Structure life (km) | 50 | |
Operation voltage range (V) | Head logic (Vdd) | 2.7 ~ 5.25 |
Head and motor drive(Vp) | 4.2 ~ 8.5 | |
Dimensions (mm) | 68.4W*16.9D*31H | |
Weight (g) | Approach 35 |
Xiamen Sanor Electronics Co.,Ltd. is one of professional thermal printer providers and highly specialized in designing,developing,manufacturing and marketing of printing.
With rich of experience and professional R&D team,Sanor successfully launched a series of printing equipment.Such as portable printers,bluetooth printers,micro panel printers,Kiosk printers,POS receipt printers,barcode label printers,as well as printer mechanism and so on.
There are some pictures of our company as following:
1.we own the advanced production facilities for manufacturing printers.
2. our company employee the skill-full workers, almost service in our company for over 4 years.
3.we have the professional team in sourcing and quality inspection team. Every printer will request for abundant of times inspection from raw material to a finished product, such as raw material sourcing assessment, incoming material inspection, PCB board test, auto cutter test,printerhead test... finished printer test and so on.
4.our experienced packing team will pack every printer in strong carton in best way for air/seaworthy transportation.
We take care of everyting from manufacturing to goods arrival!
1, Q: Are you a factory or trading company?
Sanor: We are a manufacturer,owing the professional design group,skill-full staffs and quality inspection team,located in add:3/F,No.318,Tongji South Road,Jimei District,Xiamen,China,361021.
2, Q: We would like to have our own brand, is that ok?
Sanor: Yes, we can accept OEM/ODM with your brand or your design. But we will require a MOQ for different models.
3, Q: Besides the English language, do your printers support other languages? And what operation system they backup?
Sanor: Yes, our printer not only supports English language, but also Russian, Spanish, Portuguese etc 48 different languages available, and it backups iOS, Android, Windows, Linux operation systems.
4, Q: How much your sample?
Sanor:(1) Samples charge:According to your order printer. Sampling time:5-7days
(2) Return:the sample charge will be return when we get your large order.
5, Q: What sale after service do you offer?
Sanor: Each printer will have 12 months warranty. Free components will be offered for repair in warranty period, if the issue caused by non-artificial damages.
Packing:4units/ctn, 1carton is 15kg;
Shipping:Air/sea/express
