58mm thermal printer mechanism compatible with MP-205LV/HS
Feature:
- Compatible with APS MP205-LV/HS
- Paper width:57±1mm
- Easy paper load
- Compact design
- Low Noise
- No loose wiring (a single flex-cable houses all wiring)
- Ergonomic design (centered paper path allows uniform and aesthetic housing design)
- High reliability due to its patented easy loading design
- Print speed up to 85 mm/s
Specification:
| Printing method: | Thermal |
| Number of dots: | 384 |
| Resolution (dots/mm): | 8 |
| Printing width (mm): | 48 |
| Paper width (mm): | 58 |
| Max. paper thickness (um): | 80 |
| Paper loading: | Easy loading |
| Printing speed (mm/s): | 85 |
| Paper detection: | Opto sensor |
| Temperature detection: | Thermistor |
| Head-up or Cover-open detection: | Combined with opto sensor |
| Voltage range (Logic/Head): | 2.7-5.25 / 2.7-7.2or4.5-8.5V |
| Dot resistance (Ohm): | 123/176 ± 4% |
| Energy per dot (mJ): | 0.15 |
| Stepper motor (Ohm): | Bipolar (12) |
| Weight (g): | 40 |
| Life/reliability: | 50km/100M pulses |
| Operating temperature (C): | 0 to 50 non cond. |
| Operating humidity (%): | 20 to 85 non cond. |
| Dimensions (WxDxH mm): | 68.3x41x15 |
Application:
- EFTs POS
- E-POS;
- Fiscal printers
- Automotive
- Medical equipments
- Portable printers and terminals
- Hand held terminals
- Measuring Instruments and Analysers
- Cash register
- Weighing machines and Scales
- Digital tachometers
Xiamen Sanor Electronics Co.,Ltd. is one of professional thermal printer providers and highly specialized in designing,developing,manufacturing and marketing of printing.
With rich of experience and professional R&D team,Sanor successfully launched a series of printing equipment.Such as portable printers,bluetooth printers,micro panel printers,Kiosk printers,POS receipt printers,barcode label printers,as well as printer mechanism and so on.
There are some pictures of our company as following:
1.we own the advanced production facilities for manufacturing printers.
2. our company employee the skill-full workers, almost service in our company for over 4 years.
3.we have the professional team in sourcing and quality inspection team. Every printer will request for abundant of times inspection from raw material to a finished product, such as raw material sourcing assessment, incoming material inspection, PCB board test, auto cutter test,printerhead test... finished printer test and so on.
4.our experienced packing team will pack every printer in strong carton in best way for air/seaworthy transportation.
We take care of everyting from manufacturing to goods arrival!
1, Q: Are you a factory or trading company?
Sanor: We are a manufacturer,owing the professional design group,skill-full staffs and quality inspection team,located in add:3/F,No.318,Tongji South Road,Jimei District,Xiamen,China,361021.
2, Q: We would like to have our own brand, is that ok?
Sanor: Yes, we can accept OEM/ODM with your brand or your design. But we will require a MOQ for different models.
3, Q: Besides the English language, do your printers support other languages? And what operation system they backup?
Sanor: Yes, our printer not only supports English language, but also Russian, Spanish, Portuguese etc 48 different languages available, and it backups iOS, Android, Windows, Linux operation systems.
4, Q: How much your sample?
Sanor:(1) Samples charge:According to your order printer. Sampling time:5-7days
(2) Return:the sample charge will be return when we get your large order.
5, Q: What sale after service do you offer?
Sanor: Each printer will have 12 months warranty. Free components will be offered for repair in warranty period, if the issue caused by non-artificial damages.
Packing:4units/ctn, 1carton is 15kg;
Shipping:Air/sea/express
