80mm 3inch Parallel/Serial/USB Kiosk ticket thermal printer Kiosk printer with auto cutter
- 10000 Unit / Units per Month
- Xiamen China
- Credit Card
You May Like
-
80mm RS232/TTL/USB kiosk ticket thermal printer for automatic ticket vending printer
-
58mm KP-628D receipt and ticket kiosk thermal printer for parking ticket machine
-
3 inch 80mm auto cutter RS232/TTL/USB kiosk thermal printer kiosk printer module for ATM printer
-
3'' 80mm Kiosk Thermal Printer Thermal Printer Mechanism for parking ticket system
-
2 inch kiosk thermal printer module for cash machine kiosks with cutter
-
KP-532 3inch kiosk thermal printer queue ticket printer with auto cutter
Product Details
Products Status | Stock | Type | Other, Thermal line printing | |
Style | Black And White | Use | Other, thermal printing | |
Interface Type | Other, Parallel+Serial+USB | Max Paper Size | 80mm | |
Black Print Speed | 200mm/s | Color Print Speed | No | |
Max. Resolution | 8 dots/mm,640 dots/line | Brand Name | SANOR | |
Model Number | KP-532 | Place of Origin | Fujian, China |
Product Description
80mm 3inch Parallel/Serial/USB Kiosk ticket thermal printer Kiosk printer with auto cutter
Feature:
- 80mm thermal coffee shop kiosk designs with auto cutter
- Compatible Compatible with EPSON M-T532AF/AP
- Paper width:79.5 ± 0.5 mm
- Easy paper load
- Compact design
- Low Noise
- Rubber ruller and paper ending detect
- Mechanism life(150KM)
- High speed(150 mm/s,24VDC)
- Printing width :80mm
Be applicable for 3inch printer terminal,Ticket printer terminal,barcode printer ,bank terminal,kiosk printer, ATM Printer , measure and medical treatment equipment
Specification:
Type | KP-532 | |
Printing | Print method | Thermal dot line printing |
Number of dots/line | 640 | |
Resolution | 8(dots/mm) | |
Speed(mm/s) Max. | 200(24VDC) | |
Printing width | 80 | |
Paper | Paper width (mm) | 79.5 ± 0.5 |
Max. paper thickness (μ) | 80 | |
Paper supply method | Straight ahead | |
Paper feed precision | 0.125mm | |
Detection | Paper detection | Opto sensor |
Head temperature detect | Thermistor | |
Rubber ruller detection | With | |
Power supply | Drive voltage | 24±10% |
Logical voltage | 3.0-5.5 | |
Reliability | printer head | 150km/100M pulses |
Auto-Cutter | 1,000,000cuts | |
Operating temperature (C°) | 0~50 | |
Operating humidity(%) | 20~85 | |
Dimensions (WxDxH mm) | 91.8D*126.8W*57.5H | |
Weight (g) | 532 | |
Compatible Model | EPSON M-T532AF/AP |
Xamen Sanor Electronics Co.,LTD. is a professional printing solutions of high and new technology Company. with the factory Located in the beautiful coastal city - xiamen.The company since was established,has been focused on bill printing field, always adhere to independent innovation, and has a number of intellectual property rights, after years of development and technology accumulation, the company designed and developed a variety of printing equipment are very popular with the masses of customers at home and abroad. Is the current domestic professional micro print solution development and one of the manufacturers.
1.we own the advanced production facilities for manufacturing printers.
2. our company employee the skill-full workers, almost service in our company for over 4 years.
3.we have the professional team in sourcing and quality inspection team. Every printer will request for abundant of times inspection from raw material to a finished product, such as raw material sourcing assessment, incoming material inspection, PCB board test, auto cutter test,printerhead test... finished printer test and so on.
4.our experienced packing team will pack every printer in strong carton in best way for air/seaworthy transportation.
We take care of everyting from manufacturing to goods arrival!
Packing:5units/ctn, 1carton is 13.5kg;
Shipping:Air/sea/express
1, Q: Are you a factory or trading company?
Sanor: We are a manufacturer,owing the professional design group,skill-full staffs and quality inspection team,located in add:3/F,No.318,Tongji South Road,Jimei District,Xiamen,China,361021.
2, Q: We would like to have our own brand, is that ok?
Sanor: Yes, we can accept OEM/ODM with your brand or your design. But we will require a MOQ for different models.
3, Q: Besides the English language, do your printers support other languages? And what operation system they backup?
Sanor: Yes, our printer not only supports English language, but also Russian, Spanish, Portuguese etc 48 different languages available, and it backups iOS, Android, Windows, Linux operation systems.
4, Q: How much your sample?
Sanor:(1) Samples charge:According to your order printer. Sampling time:5-7days
(2) Return:the sample charge will be return when we get your large order.
5, Q: What sale after service do you offer?
Sanor: Each printer will have 12 months warranty. Free components will be offered for repair in warranty period, if the issue caused by non-artificial damages.
