Specifications
30 years professional manufacturing condenser/evaporator experienceROHS,ISO9001.LFGB certificate
Good supplier for Midea
1.30 years professional manufacturing condenser/evaporator experience
2.ROHS,ISO9001.LFGB certificate
3.Good supplier for Midea Refrigerator
4.OEM
5.No frost, freon-free
Refrigerator Copper Tube Evaporator
Specifications: | |||
High heat exchange efficiency | |||
Energy saving, Corrosion-resistant | |||
Environmental protection, | |||
Raw Material | 1)Rolling welded steel tube : Out Diameter 8mm , Wall Thickness 0.6-0.71mm; | ||
2)Low carbon steel wire O.D.1.4-1.5mm | |||
3)Bracket:Steel Plate (SPCC),thickness 0.6-0.8mm | |||
Structure | 1)Evaporator for single temperature control system (single capillary evaporator) | ||
2)Evaporator for double temperature control system (double capillary evaporator) | |||
3)Evaporator for three way temperture control system (three capillary evaporator) | |||
Key Process | Tube bending, Tube welding, Mono shelf assemble, Assembly welding, Leakage testing | ||
Coating, Inspection, Package | |||
Technical Ability | 1)The distance of steel wire ≥6mm | ||
2)Produce according to the drawing or sample supplied by clients | |||
Performance | 1)Surface treated with powder painting or dip coating to prevent the corrosion1) | ||
2)Inner cleanness can meet the requirement of R134a &CFC cooling system | |||
3)Can satisfy the cooling capability requirements | |||
4)Producing Capacity: 3000 piece/Day | |||
R134a Cooling System Tube Inside Standards | |||
Residual Moisture | ≤20 mg/m2 | ||
Residual Impurity | ≤30 mg/m2 | ||
Residual Mineral Oil | ≤7 mg/m2 | ||
Residual Chlorine | ≤0.3 mg/m2 | ||
Residual Paraffin | ≤0.2 mg/m2 | ||
Specification of Coating | |||
Coating Thickness | Thickness of coating 30-100um | ||
Harness of Coating | ≥2H | ||
Impact of Coating | 50 cmkg/cm impact, no crack | ||
Adhesion of coating | ≥ two grade | ||
Flexbility of Coating | Around R=3D bend 180°,no crack or no fall off | ||
Color tolerance of Power Painting | E ≤ 1.5 | ||
| |||
Professional manufacturer for evaporator and condenser
Professional factory: | Specialized in the production of refrigerator condenser and evaporator in 1984 .We have about 30 years experience in development and practical experience. |
Technology: | It owns over 50 sets of equipment imported from Italy & Switzerland and more than 10 sets of specialized testing and detecting equipment. |
OEM: | operate with Aucma, Little Swan, Midea, LG, TCL and other well-know domestic and foreign enterprises. |
Advantages: | Freon-free, high efficiency and energy saving. |
Production capacity: | Relying on the advanced equipments and our staff effort, the production capacity has reached 3.5 million sets a year. |
Certificates:
CANTACT:
TEL:+86-716-8390039
MOB:+86-15090741821
SKYPE:Leanne201188
WEB:http://jztaijia.en.china.cn/
We can supply and produce new design products according to your requirment, and we also can help you to design new samples. If you are interested in our products, PLS cantact me and we will quote you the details .
