Resistance-type, 220v led button indicator B2-BV

FOB Price

USD $0.2 - $10 / Piece

10 Pieces(Min.Order)

Supply Ability 500000 Piece / Pieces per Month
Port Shanghai or Ningbo
Payment TermsT/T L/C D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	KND led button indicator
Model Number	led button indicator B2-BV

Product Description

Specifications

1. led button indicator
2. CCC,CE ,ISO9001:2008,IAF,UKAS
3. certified as Yellow Supplier by CHINT

Description

These are our company's led button indicator models in the picture , you can add X before the led button indicator models. If you want one waterproof led button indicator for sample ,please contact us .thank you.

led button indicator LED

Nominal voltage

AC/DC 6V

AC/DC 12V

AC/DC 24V

AC110V

AC220V

AC380V

LED life

≥ 30000hours

LED color

Voltage limitation

0.85Un≤U≤1.1Un

led button indicator Technical Parameters
Nominal insulation voltage Ui(V)	380V
Rated current lth(A)	10A
Rated operational voltage ue(v)		380	250	240	125
Rated operationalcurrent le(A)	AC-15	2.5		3
	DC-13		0.27		0.55

led button indicator Environment Features
Match a standard	CB14048 5-2008,IEC 60947-5-1
Ambient temperature	-25°c- +55°c
Vibration resistance	≤ 500HZ , amplitude about 1.0mm
Shock resistance	≥10g
Protection level	IP40,IP65

Elucidation	Color		Reference
		white	B2-BV61
		green	B2-BV63
		red	B2-BV64
		yellow	B2-BV65
		blue	B2-BV66
		white	B2-BV71
		green	B2-BV73
		red	B2-BV74
		yellow	B2-BV75
		blue	B2-BV76

Our led button indicator have function

Our led button indicator use the fireproof material which can protact it from burning

Our led button indicator screw is done by environmental protection plating,after the special technology,it is better to stand wear and tear

The led button indicator contact is done by silver alloy ,which is riveting full-automatic and the working life is more than one hundred thousand times.

PACKAGING

1 If the quantity is big enough ,we can do led button indicator
packaging according to your requirement and in your brand .There is no extra charge for you.

2 Each led button indicator is sealed by polythelene bag .It can be always in good condition no matter how long it is in stock.

3 Every led button indicator box also is sealed by polythelene bag,protecting the goods from water.Even though it is shipped by sea.

4 The led button indicator are using standard packaging.
