Illuminated Panel Switch , Push Lock Switch ,KD39A-11TD,NO+NC

Specifications

Description

           Zhejiang Kenaida push button CO.,LTD is a professional push button and  indicator manufacturer,Through years of painstaking operation and development , we had own more than 30 series of push button and accessories , and researched 1-2 series of new products.

           These are our company's models in the picture , please remind us which type and color you want .thank you .If you want one piece ,please contact us.

Environment Features
Match a standard	CB14048 5-2008,IEC 60947-5-1
Ambient temperature
Protection level	IP40

LED
Nominal voltage	AC/DC 6V	AC/DC 12V	AC/DC 24V
	AC110V	AC220V	AC380V
LED life	≥ 30000hours
LED color
Voltage limitation	0.85Un≤U≤1.1Un

Take the light even knob from the lock switch
Elucidation	Color		Contact type	Model number
		white	1NO+1NC	KD39A-11TD
		green	1NO+1NC	KD39A-11TD
		red	1NO+1NC	KD39A-11TD
		yellow	1NO+1NC	KD39A-11TD
		blue	1NO+1NC	KD39A-11TD
		clean	1NO+1NC	KD39A-11TD

PACKAGING

1 If the quantity is big enough ,we can do the packaging according to your requirement and in your brand .There is no extra charge for you.

2 Each product is sealed by polythelene bag .It can be always in good condition no matter how long it is in stock.

3 Every box also is sealed by polythelene bag,protecting the goods from water.Even though it is shipped by sea.

4 The goods are using standard packaging.

EXPORTING

1 Our customers are all around the world and the quantity demand is large.After the payment ,the samples will be sent ASAP.

2 After confirming the payment ,the samples will be sent by DHL,UPS,FEDEX and so on .

3 We can help your agent which in china to deal with the exporting process.

4 The goods also can be exproting by your trading company .

5 You can contact our sale department for more details
