Help CenterFlat Momentary Push Button Led Switch,KD38C-11D ,NO+NC
Related Products
-
Selector Actuator , 2or 3 Position Switch,KD38C-11X/2 ,NO+NCNegotiableMOQ: 10 Pieces -
2 or 3 Position Selector Switch ,rotary Switch With a Light KD38C-11XD ,NO+NCNegotiableMOQ: 10 Pieces
-
2 or 3 Position Switch Key Selector Actuator KD38C-11Y/2 ,NO+NCNegotiableMOQ: 10 Pieces
-
Green Mushroom Emergency Release Push Button, KD38C-11M ,NO+NCNegotiableMOQ: 10 Pieces
-
Illuminated Mushroom Push Button Switch, Self-locking ,KD38C-11MD ,NO+NCNegotiableMOQ: 10 Pieces
Specifications
1. contact type: NO+NC2. flush button with led
3. many colors
Description
Zhejiang Kenaida push button CO.,LTD is a professional push button and indicator manufacturer,Through years of painstaking operation and development , we had own more than 30 series of push button and accessories , and researched 1-2 series of new products.
These are our company's models in the picture , you can add X before the models.please remind us which type and color you want .thank you .If you want one piece ,please contact us.
| Technical Parameters | |||||
| Nominal insulation voltage Ui(V) | 380V | ||||
| Rated current lth(A) | 10A | ||||
| Rated operational voltage ue(v) | 380 | 250 | 240 | 125 | |
| Rated operationalcurrent le(A) | AC-15 | 2.5 | 3 | ||
| DC-13 | 0.27 | 0.55 | |||
| Environment Features | |
| Match a standard | CB14048 5-2008,IEC 60947-5-1 |
| Ambient temperature | |
| Protection level | IP40 |
| Contact Features | |
| Contact action | fast move NO or NC |
| Contact resistance | ≤ 50mQ |
| Mechanical life | ≥1000000 |
| Electrical durability | AC ≥100000 |
| Short-circuit protection | RT16-10A |
| LED | ||||||
| Nominal voltage | AC/DC 6V | AC/DC 12V | AC/DC 24V | |||
| AC110V | AC220V | AC380V | ||||
| LED life | ≥ 30000hours | |||||
| LED color |
|
|||||
| Voltage limitation | 0.85Un≤U≤1.1Un | |||||
| The even knob take a light | ||||
| Elucidation | Color | Contact type | Model number | |
|
|
|
green | 1NO+1NC | KD38C-11D |
| red | 1NO+1NC | KD38C -11D | ||
| yellow | 1NO+1NC | KD38C -11D | ||
| blue | 1NO+1NC | KD38C -11D | ||
| white | 1NO+1NC | KD38C -11D | ||
PACKAGING
1 If the quantity is big enough ,we can do the packaging according to your requirement and in your brand .There is no extra charge for you.
2 Each product is sealed by polythelene bag .It can be always in good condition no matter how long it is in stock.
3 Every box also is sealed by polythelene bag,protecting the goods from water.Even though it is shipped by sea.
4 The goods are using standard packaging.
EXPORTING
1 Our customers are all around the world and the quantity demand is large.After the payment ,the samples will be sent ASAP.
2 After confirming the payment ,the samples will be sent by DHL,UPS,FEDEX and so on .
3 We can help your agent which in china to deal with the exporting process.
4 The goods also can be exproting by your trading company .
5 You can contact our sale department for more details
