Master Control Gear Series Switch Group Control Box Start Switch LA10-1S

Master Control Gear Series Switch Group Control Box Start Switch LA10-1S thumbnail-1
Master Control Gear Series Switch Group Control Box Start Switch LA10-1S photo-1
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
KND
Model Number:
LA10-1S
Use:
Universal
Contact Supplier Request Quote Chat Now
Zhejiang Kenaida Pushbutton Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Standard exporting packaging
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name KND
Model Number LA10-1S
Use Universal
Place of Origin Zhejiang, China

Specifications

pushbutton control box
one push button
master control gear series

Description



           Zhejiang Kenaida push button CO.,LTD is a professional push button and  indicator manufacturer,Through years of painstaking operation and development , we had own more than 30 series of push button and accessories , and researched 1-2 series of new products.







Cope of application



LA10 series be used in electric circuit which AC 50Hz below 380V voltage ,CD below 220 voltage .



Normal working condition and installation conditions
Ambient air temperature:-5degree- +40 degrees, the average below +35degree in 24 hours.
Altitude:below 2000m
Atmosphere condition: when the highest temperature is +40 degree,the air relative humidity below 50%,the low temperature can allow a higher relative humidity.



Pollution grade: 3 grade



Installation Class:second





model button quantity contact protect type color L L1 L2 A B
LA10-1S 1 1NO+1NC waterproof red green black 110 66 82 82 34 5.5
LA10-2S 2 2NO+2NC waterproof red green 144 66 82 118 48 5.5
LA10-3S 3 3NO+3NC waterproof red black green 180 66 82 154 48 5.5


AC-15 DC-13
Ue(V) le(A) Ue(V) le(A)
380 0.8 220 0.3
220 1.4 110 0.6



master control gear series switch group control box start switch LA10-1S



PACKAGING



1 If the quantity is big enough ,we can do the packaging according to your requirement and in your brand .There is no extra charge for you.



2 Each product is sealed by polythelene bag .It can be always in good condition no matter how long it is in stock.



3 Every box also is sealed by polythelene bag,protecting the goods from water.Even though it is shipped by sea.



4 The goods are using standard packaging.







EXPORTING



1 Our customers are all around the world and the quantity demand is large.After the payment ,the samples will be sent ASAP.



2 After confirming the payment ,the samples will be sent by DHL,UPS,FEDEX and so on .



3 We can help your agent which in china to deal with the exporting process.



4 The goods also can be exproting by your trading company .



5 You can contact our sale department for more details
