turning alloy-wire drawing machine
- 50 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Inlet Diameter: | 1.5mm | Outlet Diameter: | 0.4-0.8mm |
Place of Origin: | Jiangsu, China | Brand Name: | Jiacheng | Model Number: | JCJX-FZ17 |
Voltage: | 380V 50/60HZ | Power(W): | 8000 | Weight: | 2000KG |
Certification: | CE,ISO9001:2008,TUV | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
turning alloy-wire drawing machine1,double inverter control
2,making wire from 1.5 to 0.4-0.8 mm
3, with CE ISO TUV
turning alloy-wire drawing amchine is used for drawing fine copper wire from 1.5mm to 0.40-0.80mm.
2. Technical parameter:
Model | JCJX-FZ17/B |
Application | Nickel alloy & Copper alloy |
Control type | Dual inverter +PLC +HMI |
Max inlet dia. | 1.00mm |
Outlet dia. | 0.20-0.40mm |
Max dies No. | 17 |
Final capstan dia. | 223mm |
Max line speed | 4m/s |
Lubricant type | Immersed type by turning |
Main motor power | 4KW |
Take-up type | Shaft type(pneumatic clamping) |
Take-up motor | 1.1KW |
Traversing type | Stepping motor |
Transmission | Teeth belt +Flat belt |
Take-up bobbin | DIN160/DIN200/DIN250 |
Break | Electric-magnetic break |
Feature of Drawing Machine:
1 Fully immersed lubricant system,transmission by teeth belt,constant tensio, low noise,high efficiency.
2 Capstan made by special tool steel.
3 PLC control ,dual motor,dual inverter,colour touchscreen.
4 Special alignmnt device at final die position,keep wire verticality and quality,which is good for next process.
5 Stepping motor traverse,pitch adjustable,smooth traversing.
6 Protection device for wire disorder;Machine auto stop if mother wire disordr or break.
7 Specially for drawing alloy wire and high tension strength material.
3.Product images:
4. Advantage:
1). Double inverter can keep the outlet wire precisely tension and the slip ratio of wire will be reduced to the minimum.
2). Machine’s body and other key components and parts are produced by our own factory, quality is reliable
3).High tension durably flat belt gain convenient replacement and low noise in operating.
4).we only use elcctronic components of international well-known manufactures,such as:Japan NSK bearing,Switzerland SKF belt,France Schneider electric and Shenzhen Inovance inverter.
5).we have gotten ISO 9001:2008,CE and TUV certificate.
5.After-sell service
Pre-sale training:In order to guarantee the customers are able fully to operate the machine, if the customer need, we can help customer training, includes:
(1) Correct operating mode
(2) Correct maintenance way
(3) Remove simple problem
Guarantees
Since the shipment date, 12 month for mechanical part, and 6 month for electrical part.
About our company
Jiangsu Jiacheng Machinery Co,.Ltd,was founded in 1990,owing a technical team formed by many experts and engineers,our company is concentrated on making the best products in China.we are professional manufacturer in making all kinds of high speed wire drawing machine,rigid frame standing machine,annealing and tinning machine,bunching machine,extruder and so on. And our products have exported to India,Iran,Pakistan,Vietnam,Malaysia,Kenya,Syria,Brazil,Egypt and so on.
attend the exhibition:
