Specifications
1250 mm copper wire double twist bunching machine1. PLC control
2.1-3 mm wire bunching
3. 1250 mm bobbin
1250 mm copper wire double twist bunching plant is suitable for copper wire or PVC insulated wire or aluminum wire udder 7 strands conductor to concentric twisted, mainly used for cross section for 50mm2.
Machine type |
JC-φ1250D |
Wire product of stand |
Special use twist aluminum and copper round press dowm the conductor |
Cooper wire individual |
Φ1.0-3.0 MM |
Finish stranded wire/max. |
10 mm φ/max |
Finish stranded wire/Max. |
15mm φ/max |
Section of strand-twisting(Flexible strand) |
3.5÷70mm2(6AWG÷450MCM) |
Section of strand-twisting(Semi-frametwisting1+6) |
3.5÷50mm2(6÷1/0AWG) |
Section of compaction Cu |
3.5÷50mm2(6AWG÷300MCM) |
Section of compaction Al |
3.5÷70mm2(6AWG÷301MCM) |
Line speed/Max. |
150mpm/max |
Stand pitch(mm) |
40-350mm |
60 |
8000rpm/max.(1600TPM) |
Load weight/Max. |
3000KG |
paction angle |
13% |
Traction pulley |
2×φ600mm |
Standing Direction |
S,Z Direction |
Main motor(DC/AC/HP) |
45kw D.C. motor |
Drive of Capstan(DC/AC/HP) |
30kw D.C. motor |
Drive of take-up unit(DC/AC/HP) |
7.5kw D.C. motor |
Drive of traverser |
0.75kw Inverter motor |
Drive of loading&unloading |
1.5kw Inverter motor |
Power control |
Digital type DC control |
Revise system |
Line speed synchronous auto control |
Spool bobbin size OD |
OD:φ1250 mm/Max |
Spooler size OW |
950×800×80(mm) |
Control system |
PLC man-machine interface |
Tension control |
Coiling motor indicates tension control |
Lay stranding pitch |
PLC digitization setting |
Operating direction |
Left/ right hand machine |
Traversing width |
1000mm/Max |
Traversing unit |
Wire diameter setting by digital type |
Take-up type |
Reel taken between pneumatic pintles |
Reel loading & unloading |
Liquefaction automatic positioning |
Brake system |
Disc brake |
Bearing lubricative type |
Oiling regularly |
Air pressure |
6kg/cm2 |
Voltage |
380V 50Hz |
Noise level |
80db |
Machine size |
(L)6030×(W)2280×(H)2280mm |
Weight |
12500kg |
