House Wire Extruding Machine

Name: House Wire Extruding Machine
Brand: Jiacheng
SKU: 133581099

House Wire Extruding Machine thumbnail-1

House Wire Extruding Machine thumbnail-2

House Wire Extruding Machine thumbnail-3

House Wire Extruding Machine thumbnail-4

House Wire Extruding Machine thumbnail-5

House Wire Extruding Machine thumbnail-6

US$ 17,000 - 35,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Application:

Wire

Plastic Processed:

Contact Supplier Request Quote Chat Now

Jiangsu Jiacheng Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ShangHai Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application Wire

Plastic Processed PE

Screw Design Single-screw

Automatic Grade high

Place of Origin Jiangsu, China

Brand Name Jiacheng

Model Number JCJX-30 wire extruding machine

Voltage 380V 50/60HZ

Power(W) 21000

Dimension(L*W*H) 20m 3m 2m

Weight 5000kg

Certification CE,ISO9001:2008

After-sales Service Provided Engineers available to service machinery overseas

house wire extruding machine is used for the insulation of wire and cable

with PVC LDPE, LSHF, NYLON, TPU, ABS, PP, PE

Also it can be equipment with triple co-extrution crosshead and double layer.

CONSISTING COMPONENTS

1, Φ630 non-shaft rack for pay-off

2.straightening table

3.dryer

4.suction

5. Φ30 main machine

6.electric cabinet

7.forepart sink

8.wire’s measure and control instrument

9.high speed printer

10.fixed sink

11.haul-off machine

12.9 meters accumulate rack

13.power frequency spark machine

14 counter table

15.double-shaft take-up machine

Technical parameter

Machine model	JCJX-30
Screw diameter	Ø30
L/D ratio	25:1
Rotation speed(m/min)	20-110
PVC extrusion capacity(kg/h)	25
LDPE extrusion capacity(kg/h)	16
PP extrusion capacity(kg/h)	13
Main-machine power(KW)	5.5
Finished wire dia.(mm)	0.2-1
Line speed(m/min)	10-650
Pay-off power(kw)	2.2
Pay-off bobbin(mm)	400-630
Haul-off unit	Capstan type
Accumulate length(m)	220
Take-up bobbin dia.(mm)	400-630
Electrical control	PLC

4.Wordwild markets

We are one of the top 10 manufacturers of producing wire and cable machinery in China,we export to India,Iran,Pakistan,Vietnam,Malaysia,Kenya,Syria,Brazil,Egypt,Bangladesh Burma and so on.

5.About us:

Jiangsu jiacheng machinery CO.LTD was founded in 1990,we are professional manufacturer in making all kinds of high speed wire drawing machine,rigid frame standing machine,annealing and tinning machine,bunching machine,extruder and so on.
