High Speed Cu-Cu Copper Plating Machine
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Coating Production Line | |
| Substrate | Copper | Coating | Plating | |
| Place of Origin | Jiangsu, China | Brand Name | Jia Cheng high speed Cu-Cu copper plating machine | |
| Model Number | JCJX-3000A/5000A/8000A high speed Cu-Cu copper plating machine | Voltage | 380V | |
| Power(W) | 36KW | Dimension(L*W*H) | 23000*1600*1600mm | |
| Weight | 5000KG | Certification | CE/TUV/ISO | |
| Warranty | ONE YEAR | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
high speed Cu-Cu copper plating machine
high speed Cu-Cu copper plating machine feature:
It can make copper plating copper(Cu-Cu) wire.
1.Double floor water tank,save space.
2.Six rollers,the whole rack made of stainless steel.
3.Main motor by frequency control.
4.Take-up part controlled by torque motor,stable tension.
Machine model | JCJX-3000A | JCJX-5000A | JCJX-8000A |
Control system | Button type | ||
Main power control | Controlled by high frequency switch power | ||
Take-up power control | Controlled by torque motor | ||
Wire diameter | 1.00-1.20mm | 1.20-1.60mm | 1.60-3.00mm |
Main motor | 4KW | 5.5KW/7.5KW | 7.5KW/11KW |
Take-up motor | YLJ132-16 | YLJ132-40 | YLJ132-40 |
Spool reel size | 300mm or according to customers requirements | 630mm or according to customers requirements | |
Take-up type | Shaftless take-up M/C | ||
Traversing type | Plam shaft type | ||
Transmission type | Tri-angle belt,chain | ||
Line speed | 0-100m/min | 0-120m/min | 0-120m/min |
Rectifier | 3000A | 5000A | 8000A |
Dimension(mm) | 18000*1200*1400 | 22000*1600*1600 | 23000*1800*1600 |
Weight | 4000KG | 5000KG | 6500KG |
