high speed Cu-Cu copper coating machine
high speed Cu-Cu copper coating machine feature:
It can make copper coating copper(Cu-Cu) wire.
1.Double floor water tank,save space.
2.Six rollers,the whole rack made of stainless steel.
3.Main motor by frequency control.
4.Take-up part controlled by torque motor,stable tension.
Machine model |
JCJX-3000A |
JCJX-5000A |
JCJX-8000A |
Control system |
Button type |
||
Main power control |
Controlled by high frequency switch power |
||
Take-up power control |
Controlled by torque motor |
||
Wire diameter |
1.00-1.20mm |
1.20-1.60mm |
1.60-3.00mm |
Main motor |
4KW |
5.5KW/7.5KW |
7.5KW/11KW |
Take-up motor |
YLJ132-16 |
YLJ132-40 |
YLJ132-40 |
Spool reel size |
300mm or according to customers requirements |
630mm or according to customers requirements |
|
Take-up type |
Shaftless take-up M/C |
||
Traversing type |
Plam shaft type |
||
Transmission type |
Tri-angle belt,chain |
||
Line speed |
0-100m/min |
0-120m/min |
0-120m/min |
Rectifier |
3000A |
5000A |
8000A |
Dimension(mm) |
18000*1200*1400 |
22000*1600*1600 |
23000*1800*1600 |
Weight |
4000KG |
5000KG |
6500KG |
