Specifications
CO2 Laser Cuttng Machine1.cutting area 1300X2500mm
2.cutting acrylic,wood,metal
3.high precision ball screw
4.servo motor
Laser Cuttng Machine
JMSCJG-130250 laser cutting machine
Advantages of GOLDEN LASER Cutting Solution for metal and solid materials:
1. Cost efficiency by the application of low maintenance technologies and maintenance-free lasers
2. Engrave and cut a wide variety of materials
3. One machine cutting both metal and non-metal
4. Faster speed and higher precision
5. Global pioneer for double core laser processing system
6. Particular ultrasonic auto-focus system
7. High efficiency engraving and cutting separated system
8. High efficiency galvanometer engraving and cutting integrated technology
9. International leading laser motion control system
10. Auto-nesting
11. Fast pattern digitizing
12. Complete exhaust and filtering of cutting emissions possible
13. Ergonomic loading and unloading system without time-consuming
Application of laser cutting machine
Applicable Materials: Perfectly cutting metal and non-metal plates, such as stainless steel, mild steel, carbon steel, acrylic, wood, MDF, plywood, veneer, plastic, rubber, sponge, paper, cardboard, etc.
Applicable Industries: Suitable for sheet metal processing factories, advertising & sign firms, crafts, modeling, furniture manufacturing companies which are in need of cutting both metal and non-metal materials.
Features of laser cutting machine
1) Large format working area with steel girder structure.
2) Precision ball screw driving system and servo motor system ensure high cutting precision.
3) Coherent / Synrad CO2 RF metal laser tube produces high quality laser beam, stable power and long working life. Low use-cost, maintenance-free and high efficiency.
4) Strip panel working table reduces contacting area with work pieces, which ensures high quality cutting.
5) Following exhaust system has good performance, saving energy consumption.
6) Smart nesting function enhances utilization rate of processing material.
7) 5 inches CNC system provides online and offline for your choice, easy to use.
8) Wide application. Suitable for cutting metal and non-metal.
Samples of laser cutting machine
Main Technical Parameter of laser cutting machine
Laser Type: Coherent / Synrad CO2 RF metal laser tube
Laser Power: 500W (Standard Collocation)
100W / 150W / 200W / 300W (Optional Collocation)
Working Area: 1300mm×2500mm (1500mm×3000mm / 1300mm×900mm)
Working Table: Strip panel working table
Working Speed: Adjustable
Repeating Location Accuracy: ±0.1mm
Cooling System: Constant temperature water chiller
Motion System: Servo motor, LCD display, Ball screw driving system
Power supply: AC110V-220V 50/60Hz
Format support: AI, BMP, PLT, DXF, DST, etc.
Standard collocation: Mini air compressor, Automatic control high pressure blow valve
Optional collocation: Automatic following focusing system
Machine Dimension: 4.40×2.22×1.32(M)
Packing Size: 4.50×2.30×1.50(M)
Net Weight: 1710(KG)
Gross Weight: 1910 (KG)
Working size and laser power can be customized according to requirement.
Prompt & Good After-sale Service:
1> One year guarantee for the whole set of machines, not including normal replacement of wearing parts.
2> 24 hours technical support by email or calling. When it is necessary, we will send technician to the customer side to solve the problem.
3> User-friendly English manual and CD for machine using and maintaining.
4> Free lifetime upgrading of self-developed English software.
