Help CenterProfessional Electronics HDMI Matrix Switcher 4x4 ,Video Wall , Picture in Picture , Picture Outside Picture
Related Products
-
HDMI Splitter 1x4 With Audio Output ;supports 4KNegotiableMOQ: 50 Pieces -
HDMI SPLITTER EXTENDER 1x4 OVER SINGLE Cat5e/6 164ft , Smart ManagementNegotiableMOQ: 1 Piece
-
Ultra High Speed HDMI Splitter 1x8, 4K*2k, Super QualityNegotiableMOQ: 1 Unit
-
Ultra High Speed HDMI Splitter 1x2, 4K*2k, Hot SaleNegotiableMOQ: 1 Unit
-
New Product UHD 1x2 HDMI Splitter, 4K*2kNegotiableMOQ: 100 Units
1.Introduction
The matrix switcher is a high-performance with seamless switching output and mixed input 4x4 matrix switcher,4 mixed input to support digital video signals and analog video signal, and 4 outputs with seamless switching function, seamless switching mode: fast switching, fade in/fade out, blinds and so on; the mixing matrix switcher adopts the advanced digital technology, with scaler function, and achieve a variety of formats to achieve a unified output signal, switching seamlessly perfect visual effects. At the same time it with infrared matrix function, analog video signal input with embedded audio function. Flexible control mode diversity, through the front panel button, remote control,RS-232 and TCP/IP control.
As a video wall processor, the matrix switcher is able to zoom in one input image four times to the outputs. And as a Multi-viewer processor, the matrix switcher can mix inputs with any combos to one image, and then transfer to all the outputs.
2.Features
Compliant HDMI1.3, HDCP1.3 and DVI1.0
Input video supports HDMI, VGA and C-video
Supports input resolutions :
HDMI: 480i to 1080p
VGA:1920 x 1080P@60Hz, 1360 x 768P@60Hz,
1280 x 1024P@60Hz, 1024 x 768P@60Hz,
1280 x 720P@60Hz,1280 x 768P@60Hz, 800 x 600@60Hz,
640 x 480P@60Hz
CV: Supports PAL, NTSC3.58, NTSC4.43, SECAM, PAL/M, PAL/N standard TV formats
Supports output resolutions :1920x1080P@60Hz
Supports seamless switching output,optional seamless switching mode:fast switching,fade in/fade out,blinds and so on
The RS-232 for the firmware update
Supports RS-232, remote control, on-panel control and TCP/IP Control
Supports smart EDID management
Picture Adjustment Settings
Automatically adjust the VGA input video
Supports power-off memory
