2014 Top Sell 4Kx2K HDMI Audio Decoder Support Dolby Digital 5.1,DTS-ES 6.1 Digital Audio Decoder 5.1
US$ 46 - 47
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
playvision
Model Number:
HDA-20A
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2015 Newest Hdmi Audio Extractor Digital to Analog ConverterNegotiableMOQ: 1 Piece -
Digital to Analog Audio Converter, Digital Optical Toslink or SPDIF Coaxial to Analog L/R Audio Converter Adapter , BestNegotiableMOQ: 1 Piece
-
Upgrade DAC Digital Optical Coaxial Toslink Signal to Analog Audio Converter Adapter RCA , Best QualityNegotiableMOQ: 1 Piece
-
New Hot Coaxial to SPDIF or Toslink to Coaxial : Two-way ConversionNegotiableMOQ: 10 Pieces
-
Two-way Conversion: Coaxial to Toslink or Toslink to CoaxialNegotiableMOQ: 10 Pieces
Brand Name
playvision
Model Number
HDA-20A
Place of Origin
Guangdong, China
Specifications
digital audio decoder 5.11. No need to install drivers, portable, flexible, plug and play.
2. Compliant with HDMI 1.4, DVI 1.
digital audio decoder 5.1
n Introduction
The HDMI audio decoder increases the analog stereo audio output(RCA and earphone) On basis of the HDMI signal transmission. The HDMI audio decoder integrated an 24 bit audio DSP. It decode a variety of digital audio formats, including Dobly Digital (AC3), DTS and PCM. then be transmitted as 2 channel analog audio via the Stereo RCA output , the 3.5mm output (suitable for headphones) and the HDMI out simultaneously.
n Features
- 1. No need to install drivers, portable, flexible, plug and play.
- 2. Compliant with HDMI 1.4, DVI 1.0 standards.
- 3. Support 3D Video & 4Kx2K, 8, 10, 12 & 16 bits per color depth.
- 4. Support PCM 32K,44.1K,48K,88.2K,96K,176.4K,192KHz sample frequency audio decode.
- 5. Support Dolby Digital 5.1 samples ,DTS-ES6.1 samples audio decode.
n Package
- 1. HDMI Audio Decoder 1PCS
- 2. 5V1A DC Power 1PCS
- 3. Operation Manual 1PCS
n Operation controls and Fuctions
- 1. DC 5V: Connect the 5V DC power supply into the decoder.
- 2. POWER LED: This red LED illuminate when the device is connected with power supply.
- 3. SERVICE: Firmware update port.
- 4. HDMI input: These slot is where you connect the HDMI source output from DVD, PS3,Set-top Box or Note Book.
- 5. HDMI OUT: This slot is where you connect the HDTV or monitor with HDMI cable for input source display.
- 6. AUDIO OUT: These slot is where you connect to the audio amplifier or speaker with RCA cable or 3.5mm earphone cable.
n Application Example
- 1. Connect a source such as a Blu-Ray Player, game console, A/V Receiver, Cable or Satellite Receiver, etc. to the Docoder HDMI input.
- 2. Connect a display such as an TV or Projector to the HDMI output on the Decoder.
- 3. Connect the audio out to the audio amplifier or headphone by RCA or earphone cable.
- 4. Power on the device and display.
n Audio Format Convert
n Connect diagram
