two-way conversion: Coaxial to Toslink or Toslink to Coaxial
I. Introduction
The Digital 2-way audio converter is a Coaxial / Toslink audio converter, compact and convenient.It accepts S/PDIF audio signal
input through either Coaxial cable or Toslink cable,and passes the signal (as is) to both its coaxial and Toslink
output ports. With its builtin amplification feature, It can also serve as a repeater of audio signal and extend (double)
the transferring distance.
II. Features
Supports two-way conversion: Coaxial to Toslink or
Toslink to Coaxial.
Supports amplification of S/PDIF audio and extends the transferring distance,
through coaxial and/or Toslink cables.
Select one input from Coaxial or Toslink input ports, and
send S/PDIF audio
signal to both Coaxial and Toslink output ports
simultaneously.
Compact size and easy to install.
III. Package
Digital 2-way audio converter ----------1pc
5V DC Power Supply Adapter ----------1pc
Operation Manual -------------------------1pc
Specifications
Input: 1 x Coaxial RCA Jack;1 x Toslink (optical fiber)
Output:1 x Coaxial RCA Jack ;1 x Toslink (optical fiber)
Dimension: 66mm x 55mm x 20 mm
Weight: 40g
Power Consumption (Max): 1W
Operation controls and Function
Optical IN: Connect the Optical input to an Optical digital audio source, such as a DVD.
Coaxial IN: Connect the Coaxial input to an Coaxial digital audio source, such as a DVD.
DC IN: Plug the 5V DC power supply into the unit.
USB Power: Connect the USB power port to any powered USB with a Mini-USB cable or Mini-USB to AC adapter.
Input switch: Select the Optical or Coaxial input.
Power LED: The LED will illuminate when connected to power
Coaxial output:Connect the output ports to the Coaxial input port of audio
Optical output:Connect the output ports to the Toslink (Optical Fiber) input port of audio
V. Application Example
