600kg glass sucker manufacturers
- 40 Set / Sets per Month
- Shanghai
You May Like
Product Details
Place of Origin | Shanghai, China | Brand Name | Shanghai Freddie | |
Model Number | FVL-G600-6 | Condition | Used | |
Year | 2011 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Our Glass vacuum lifter hoist on sale, do not need cable insert. It solved the problem of the power source inconvenience in the construction site, especially for high altitude installation of curtain wall glass, and it can be customized design according to the size of glass. Our company has passed the IOS9001, and products have passed CE certification. You can trust our quality and service. For this type glass vacuum lifter, it's very popular in the glass handling site.
And our products has received good remark from our customer side, the quality and service is our success point. And considering all of the customer faced issue that we design this type of vacuum handling equipment, specialized to solve those problems, to improment your work efficient and safety. Our company has passed the ISO9001, products have passed CE certification, so you can trust our quality and service.
Packaging details: wooden pallet for export
fumigation-free
Delivery Detail: 10-15days
Load(Kg) | Type | PAD Dimension | Pads Quantity | Rotation | Swivel | Voltage | HZ | Phase | Self-weight | Overall dimensions(mm) |
400 | FVL-G400-4 | Φ300mm | 4 | 360 degree | 90 degree | 12/220/380 | 50/60 | 1/3 | 70 | 850*750*300 |
600 | FVL-G600-6 | Φ300mm | 6 | 360 degree | 90 degree | 12/220/380 | 50/60 | 1/3 | 90 | 1500*1150*300 |
800 | FVL-G800-8 | Φ300mm | 8 | 360 degree | 90 degree | 12/220/380 | 50/60 | 1/3 | 100 | 1500*1150*300 |
1000 | FVL-R1000-10 | Φ300mm | 10 | 360 degree | 90 degree | 12/220/380 | 50/60 | 1/3 | 200 | 2500*1400*300 |
1200 | FVL-R1200-12 | Φ300mm | 12 | 360 degree | 90 degree | 12/220/380 | 50/60 | 1/3 | 350 | 5000*1200*600 |
200 | FVL-GS200-2 | Φ300mm | 2 | 90 degree | 90 degree | air power | / | / | 50 | 800*400*300 |
400 | FVL-GS400-4 | Φ300mm | 4 | 90 degree | 90 degree | air power | / | / | 70 | 800*800*400 |
600 | FVL-GS600-6 | Φ300mm | 6 | 90 degree | 90 degree | air power | / | / | 90 | 160*800*400 |
Main Features:
1. using import DC charging type vacuum pump, and equipped with two batteries
2. suitable for glass length up to 15 m, width of 4 m
3. apply to the high temperature of 300 degrees glass
4. can implement handling of 0-90 degrees tilt of the glass
5. can achieve glass 0-360 degree rotation handle
6. suitable for variety of structure and suction cups are available for configuration
7. energy accumulator and pressure testing to ensure safety
8. efficient, safe, fast, and energy saving
Service Contact : Rocky Hsia
(Fax): +86 21 57644031
(P.C):201612
(Web):
Shanghai Freddie Automation Equipment Co., Ltd locates in Songjiang district which is the industrial center of Shanghai manufactures. We participate in researching, manufacturing, and trading equipment for insdurial automation,vacuum lift, logistic technology, pneumatic and assembly operation. We operate in high growth market and keep maintaining our market positioning by cooperating with well- know vacuum system and industrial transmission control technology learders from America, German, Italy and swedish.
We are dedicated to offering a complete of vacuum Handling Solutions from the component to the system level. As a customer builder of specialized vacuum equipment, we provide high quality products to machinery processing, steel manufacture, chemistry industry, food processing, wood industry, aluminum manfucture, pharmaceutical industry, plastic industry, packaging service, electronic products industry, and logistics service providers.
