Twin Screw Gap Free Extruder
A. Extruder with Hydraulic Pressure Opening Barrel
Main characteristic:
1. Hand hydraulic pressure barrel; Easy to change color and cleaning
2. Three zone PID temperature control accuracy ±1°C
3. Cooling water system inside the screw
4. Separately cooling water system in barrel No. 3 zone to avoid block water passage
5. Feeding area has permanent magnetic metal remover
6. Gear box equipped with water cooling system
7. Gear box equipped with lubricating system
8. Extruder noise lower than ≤80dB
B. Main Technical characteristic:
1.The changing during moving gap is zero
2. High disperse efficiency
3. Self-cleaning system
4. Double temperature PID control, control accuracy ±2°C
5. Barrel equipped with soft water recycle automatic cooling system
6. Low noise and high secure gear box system
7. Equipped with permanent magnetic iron remover
8. Low material consumption, electricity and material rate kg/h.kw is higher
C. Main Technical Parameter:
Model |
SFJ-46A or B |
SFJ-55A or G |
SFJ-64A or G |
SFJ-80G |
Screw diameter(mm) |
46 |
55 |
64 |
80 |
Length-diameter(L/D) |
14:1 |
16:1 |
15:1 |
15:1 |
Capacity(Kg/H) |
100~180 or 100~280 |
300~400 |
400~500 |
600~800 |
Screw motor power(kw) |
15, 6 or 22, 4 |
30 |
45 |
55 |
Feeding motor power(kw) |
0.37 |
0.37 |
0.55 |
0.55 |
Heating power(kw) |
0.75*4 |
0.75*6 |
1*5+0.75*1 |
2*5+1.5*1 |
Mixing motor power(kw) |
- |
0.37 |
0.37 |
0.37 |
Screw speed(rpm) |
0~500/0~800 |
0~500 |
0~500 |
0~500 |
Temperature control system |
±2°C Double temperature PID auto-control. Accuracy ±2 |
|||
Speed adjust system |
Adjustable speed by means of frequency inverter |
|||
Feeding system |
Variable by means of frequency inverter |
|||
Cooling system |
Water cooled |
|||
Equipped with |
Screw feeding |
|||
Permanent strong-magnetic device | ||||
Overall dimension(mm) |
|
2650*900*1900 |
2900*900*2000 |
3600*950*2260 |
D. Machine PIC
extruder with electric cabinet
machine parts:
Siemens motor
Screw:
Machining:
Our market:
Italy, Iran, Turkey, India, Thailand, Egypt, Malaysia, Czech, Poland, Russia, USA.
Factory
Yantai Yuanli Machinery Manufacturing Co., Ltd. with more than 27 years experiments, offer wide range of services in powder coating field from A to Z including know-how, technology, machinery, raw material, technical support.
Our product has been supplied all around China and exported to international market like, Italy, Iran, Turkey, India, Thailand, Egypt, Malaysia, Czech, Poland, Russia, USA.
Wlecome to visit Yuanli Manufacturing Company,tks!!
