Model: China Hot Air Welding Machinery With CE for PVC Canvas Tarpaulin Inflatables
Feature
1.Original imported computer chip design , can be programmed in accordance wit user's requirements,microcomputer automatic control the whole machine ,
simple operation , stable performance action, low failure rate .
2.It is 3 inch panasonic touch screen and can directly show all kinds of data.
3.Temperature is automatic tracking controlled by computer and its precision can reach +/-1.
4.The temperature is controlled by computer chip.twospeed motor.separate upper and lower roller motor , can adjust its speed .
5.Turn on the heating button , later turn it off and then delay the shut down , get into count down
6.No table, wide lower prop design ,suit to processing the large tents, rubber boats , air balloon, seamless sewing products, etc.
Application:
Ideal for making,welding,sewing raincoats, various big tents, truck covers for automobile, inflatable boats ,waterproof zipper,inflatable advertisement arch,life saving rings,and toys, balloon, and other products including PU, PVC, TPU, PE, PVA materials.
parameters: miller hot air welding machine
Model |
HA800 |
Power |
1800W |
Input power |
4KVA |
Voltage |
50HZ AC220V |
Temperature |
700 °C |
Working speed |
2.5m/min-18m/min |
Width of nozzle |
20-50MM (optional) |
Way of pressure |
Air |
Air pressure |
6kg/cm 2 |
Upper roller pressure |
0.5kg/c square meter- 4.5kg/ c square meter |
Upper roller stroke |
20-30mm |
Diameter of roller |
81.5mmX20-50mm (optional) |
Width of roller |
20-50mm |
Welding width |
20-50mm |
Processor |
Touch panel |
Machine dimension |
L1600×1500×1800mm |
Weight |
1000kg |
Samples: miller hot air welding machine
Our aim is to research the possibilities of this technology in joining technical textiles and flexible electronics and compare it to traditional technologies such as heat lamination. One interesting aspect also is the welding of 3D shapes. miller hot air welding machine
WE CHECK YOUR MATERIAL OUT
If you would like to know whether your material can be welded with Hot Air equipment, send us some samples for making test welds. This service is free of charge (the shipping costs must be covered by the material deliverer)
Xiehe provide you with the most thoughtful services | |
1 |
One year warranty and life long maintenance |
2 |
Free training and instruction |
3 |
Free replacements |
4 |
24 hours online service |
5 |
Sending technical staff overseas |
6 |
Customized is available |
Contact us Now !!!! | |
