Home > Electrical & Electronics > Telecommunication & Broadcasting > Set Top Box > Remote Control KXYALLWINNER A20 Dual ARM Cortex-A71.2GHz Android tv Box Remote Control

Remote Control KXYALLWINNER A20 Dual ARM Cortex-A71.2GHz Android tv Box Remote Control

US$ 31 - 45 MOQ: 1000 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

OEM

Model Number:

0004

Contact Supplier Request Quote Chat Now

Shenzhen Winnatek Aitech Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name OEM

Model Number 0004

Specifications

Frequency:Dual ARM Cortex-A7,1.2GHz
GPU:Mali-400 MP2 GPU, 2D/3D accelerator OPNE GL

Specifications
System	ALLWINNER A20 Dual-core CPU	Frequency	Dual ARM Cortex-A7,1.2GHz
		GPU	Mali-400 MP2 GPU, 2D/3D accelerator OPNE GL
		Decoding	3D acceleration,VPU:2160P Hardware decoding, 256 KB L2 Cache,3D HD video output
		Process	40-nanometer process

Configuration
Memory	DDR3,Standard 1G, up to 2GB	FLASH	Standard 4GB, up to 32GB
Interface	USB	1 USB2.0 HOST
		A USB OTG interface, which at the same time can be powered on the machine
	HDMI	HDMI interface supports standard C class, the maximum resolution support 1080P output
	WI-FI	Support IEEE 802.11B/G/N standard, high sensitivity antenna, supports both wireless routing functions
	TF card slot	A standard TF card slot, external TF card
	DC Input	Standard 2.5mm DC 5V interfaces
OS
System Description	version	Android4.0.4
	UI	Customized UI, the company also has own UI interface provides customers choose.
	Operating	Support air mouse / keyboard connected to the USB HOST interface operation	Support both USB OTG interface to connect the IR receiver extension cord (optional accessories), support for remote control operation
Formats	Audio	MP3,WMA,MP2,OGG,AAC,M4A,MA4,FLAC,APE,3GP,WAV
	Video	AVI(H.264, DIVX, DIVX, XVID, rm, rmvb, MKV(H.264, DIVX, DIVX, XVID), WMV, MOV, MP4(H.264, MPEG, DIVX, XVID), MPEG, MPG, FLV(H.263,H.264)
Accessory
List	Adapter 5V/1A
	HDMI cable - Female (optional)
	Manual
	USB cable
Advantage
Advantage	USB HOST	Support 2.4G air keyboard, wireless / wired mouse, USB keyboard, 2.4G somatosensory game handle (support the gyroscope), IR touch screen interface, USB Carema (mic) interface to support Internet telephony, USB turn URAT interface, support for plug-in GPS
	OTG	Support a basic OTG function, direct-attached printers, scanners, etc., at the same time can be used as USB DEVICE directly connected to the computer to copy data, it can be individually inserted USB DEVICE line, the external power supply of the machine
	Upgrade	Support TF card upgrade
	System Recovery	Plug in the DC interface, pressing the side of the machine "FN" button, plug in the DC interface 5S loosen the machine into the self-recovery mode, do not connect to a TV, the machine automatically re-upgrade system, and there is a red light flashing prompt
	Special thermal design	System heating adaptive adjustment, the highest temperature controlled at about 50 degrees, the current the full Chi system A10S program the lowest temperature, the most stable design
	Wireless router	WI-FI wireless routing function, you can set up a wireless LAN
	Remote operation	Support DLNA and other mobile phone remote control application operation,Support 2.4G wireless remote control of devices
	Customized design	The company has strong technical development team, and support a variety of customized development, including UI, system functions, changes in the various modules, APK
