Specifications
1. Output Effeciency>90%2. Output Frequency:60HZ/50HZ
3. Use in Home/Car/Camping
4. Input12V/24V, Output 110V/220V
Features
1. High conversion efficiency, fast start.
2. Multiple protection circuit for low voltage
3. Direct Cigarette lighter connection
4. Smart, light, easy for carry
5. Universal socket, suitable for all kinds of plugs
6.Portable size power inverter
7.With the multiple protection circuit, no harm to equipments
8.High-procision voltage stability technology
Power Inverter Specification Chart | |
| Input voltage | DC 12V(10.5-14.8V)/24V(20-28V) |
| Output voltage | AC220V,230V,240V(100V,110V,120V) |
| Continuous output Power | 1000W |
| Peak Power(Max) | 2000W |
| Waveform | Pure Sine Wave |
| Output Frequency | 50Hz/60Hz/±4Hz |
| Availability power | ≥90.5% |
| Low voltage alarm | 10.5V±0.5V |
| Low voltage range | <9.6V |
| High voltage range | >14.8V |
| Non-load current | ≤0.4A |
| Overload protection | >2100W |
| Overhear protection | >70°C |
| Fuse | 8×30A |
| Cooling fan | Yes |
| Reverse Protection | Yes |
| Short-circuit Protection | Yes |
Choosing the Right Inverter
First step is to establish the power required to run your equipment. Most appliances/ tools have their wattage stamped on the namplate or listed in the owner's manual. Simply add your appiance wattages together to arrive at a total figure. If you find you can only local the amps, use this simple alculation:240volts* Amps =Watts.
Step two is slecting the correct size invrter. Resistive loads(lights, chargers,etc.) only require your inverters rated output. Inductive loads such as an air conditioner, refrigerator/freeser requires 5-7 times the continuous rating, e.g. an 80w refrigeerator requires a 600w inverter. Power tools, fluorescent lights, TV also requires 3-4 times more wattage at start up. Therefore you would need a 1000W inverter to power a 250W drill.
Keep in mind, it's an inverter, not a power station, choosing an inverter with 25-30% above your needs is recommended. If you're unsure of your requirements, ask us or or a licensed electrician.
Angotan Products Information
Angotan Company is well-known as a leader in providing quality auto parts to the aftermarket. We've earned our reputation for excellence for long term of experience in providing automative replacement parts, fasteners and sevice line products primarily for the afermarket. Our prestigious position stems from a unique combination of application expertise, innovative product design, and breadth of product offerings, many of which are not conveniently or economically available elsewhere. At Angotan, we take pride in the quality of our products and in your satisfation.
