Help CenterThree Phase Control Transformers
Related Products
Specifications
50/60HZ Three Phase Control Transformers1.Frequency:50/60Hz
2.Weight:26~320kg
3.Phase No.:Single/Three
4.Capacity:1~50k
50/60HZ Three Phase Control Transformers
Control Circuit Power Transformer Is Widely Used In Various Electrical Equipment Circuits.
Service Conditions
1. Service Site: Indoor Or Outdoor
2. Ambient Temp.:-40~40 Degree( Or According To Customer's Requirment)
3. Altitude: <=10000m( If It Exceeding To 1000m, Pls Declare In Order).
4. Max. Wind Speed: 35m/S
5. Relative Humidity: <=90%
6. Earthquake Resistant Capability: Horizontal Direction0.3 G Virticle Direction0.15g (Or By Customer's Requirments)
Technical Parameter
Control Transformer | ||||
3-phase Control |
Frequency |
Outline |
Assembly |
Weight |
|
HZ |
L×B×H |
Dimenssion |
(kg) |
| SG-1/1.0 | 50/60 | 280×160×220 | 160×130 | 26 |
| SG-2/1.0 | 50/60 | 280×160×260 | 160×130 | 34 |
| SG-3/1.0 | 50/60 | 320×170×300 | 180×130 | 42 |
| SG-4/1.0 | 50/60 | 300×170×310 | 180×130 | 54 |
| SG-5/1.0 | 50/60 | 340×170×320 | 200×130 | 62 |
| SG-6/1.0 | 50/60 | 340×230×390 | 200×140 | 70 |
| SG-7/1.0 | 50/60 | 360×240×410 | 200×140 | 78 |
| SG-8/1.0 | 50/60 | 360×240×420 | 200×150 | 84 |
| SG-9/1.0 | 50/60 | 370×240×430 | 200×150 | 92 |
| SG-10/1.0 | 50/60 | 370×260×460 | 200×160 | 104 |
| SG-15/1.0 | 50/60 | 370×270×500 | 200×160 | 130 |
| SG-20/1.0 | 50/60 | 510×350×520 | 300×300 | 225 |
| SG-30/1.0 | 50/60 | 550×350×620 | 350×300 | 254 |
| SG-50/1.0 | 50/60 | 560×400×640 | 350×350 |
320 |
Note: Data included in the table for reference only.
Packing
Protected By Water-Repellent Cloth, Secured And Packed In Wooden Case
Delivery Time
10-30 Days Depending On Quantity Ordered
