Specifications
1.CCC PVC shield Electrical RV/RVV/RVB/RVS cable Electrical Wire2.Solid & stranded bare copper conductor
3.All kinds PVCcab
XLPE Power Cable Standard:
IEC 502-1983
XLPE Power Cable Features:
Excellent electric and mechanical properties;
Powerful resistance against chemical corrosion;
High performance of heat resistance and environmental stress resistance;
No restriction of different levels for laying
XLPE Power Cable Service conditions and parameters:
Max conductor operating temperature: 90 deg C
Short circuit temperature: >250 deg C no more than 2 seconds
Environment temperature of laying: 25 deg C (in air) 15 deg C (underground)
Depth of laying in direct: 100cm
Coefficient of thermal resistivity of soil: 100 deg C .cm/w
Coefficient of thermal resistivity of PVC: 700 deg C .cm/w
0.6 1kv IEC502 High Tension Cable N2XBY
2. Voltage :
up to 35KV
3. Specification:
Type |
Designation |
Application |
VV |
Copper conductor ,PVC insulated ,PVC sheathed power cable |
For laying indoors, in tunnel or cable trench,unable to bear extermal mechanical forces. Single core cable is not permissible to lay in magnetic duct |
VLV |
Aluminium conductor ,PVC insulated ,PVC sheathed power cable |
|
VY |
Copper conductor, PVC insulated, PE sheathed power cable |
|
VLY |
Aluminium conductor ,PVC insulated ,PE sheathed power cable |
|
VV22 |
Copper conductor ,PVC insulated ,steel tape armoured ,PVC sheathed power cable |
For laying indoors, in cable trench or direct in ground ,able to bear external mechanical forces, but unable to bear pulling force |
VLV22 |
Aluminium conductor ,PVC insulated ,steel tape armoured ,PVC sheathed power cable |
|
VV23 |
Copper conductor ,PVC insualted ,steel tape armoured ,PE sheathed power cable |
|
VLV23 |
Alunminium conductor ,PVC insulated ,steel tape armoured ,PE sheathed power cable |
|
VV32 |
Copper conductor, PVC insulated, steel wire armoured,PVC insulated power cable
|
For laying indoors, in cable or direct in ground ,able to bear external mechanical forces, but unable to bear large pulling forces |
VLV32 |
Aluminium conductor, PVC insulated ,steel tape armoured ,PVC sheathed power cable |
|
VV33 |
Copper conductor, PVC insulated steel wire armoured , PE sheathed power cable |
|
VLV33 |
Aluminium conductor , PVC insulated , streel wire armoured ,PE sheathed power cable |
|
Note: The armoured single core cables is only used for D.C.system. As for A.C.system,non-magnetic armored material should be applied | ||
