PVC PU Belt Hot Vulcanizing Press Air Bag

PVC PU Belt Hot Vulcanizing Press Air Bag thumbnail-1
PVC PU Belt Hot Vulcanizing Press Air Bag photo-1
US$ 2,000 - 20,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Beltwin
Model Number:
DLPVC
Contact Supplier Request Quote Chat Now
Wenzhou Winco Imp&Exp Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shangai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Beltwin
Model Number DLPVC

Specifications

1.Special for PVC PE PU belt
2.Water Cooling system within platens
3.Temperature range: 0~200C
4.Air pressure bag 0~0.5mpa

1. Specification

Splicing PVC, Polyurethane, and Polyester Monofilament synthetic belting



  • 1200mm width (other width on your request)
  • Easy and quick pressure build-up by means of compressed air, 0~0.3Mpa (can adjust)
  • Used for PVC belt, Polyurethane belt (PU belt) and Polyester Monofilament synthetic belting
  • Rapid Cooling system within platens
  • Reliable and automatic Temperature Control Panel with time control
  • Light weight construction with aluminum profiles
  • Temperature regulation between 0° to 200°C
  • Voltage: 220V or 380V, 400V, 415, 480V etc., other voltages on request.
  • Integrated air control with pressure gauge and safety valve
  • Packing Dimension: 2430*580*590mm
  • Gross Weight: 200KGS
Technical Datasheet:
Model Heating plate size LxW (mm) Width of the belt (mm) Total Power (W) Dimension (LxWxH) mm Total Weight KGS
DLPVC – 100×200 100×200 200 560 330 x 135 x 180 7
DLPVC – 150×250 150×250 250 1000 350 x 192 x 180 10
DLPVC -160×400 160×400 400 2200 550 x 215 x 200 20
DLPVC – 200×500 700×200 500 2300 700x200x 230 40
DLPVC – 200×600 800×200 600 2400 800x 200x 230 60
DLPVC – 200×800 1000×200 800 2800 100 0x 200x 250 90
DLPVC -200×1000 1050×200 1000 3200 1200x 200x 250 110
DLPVC -200×1200 1250×200 1200 3600 1450 x 200x 250 125
DLPVC -200×1500 1650×200 1500 4000 1850x200x460 165
DLPVC – 200×1600 1750×200 1600 4800 1950x200x460 175
DLPVC -200×1800 1950×200 1800 5280 2150x200x460 195
DLPVC-200×2000 2150×200 2000 5920 2350x200x460 210
DLPVC-200×2200 2350×200 2200 6800 2550x200x460 230
DLPVC-200×2500 2650×200 2500 8200 2850x200x620 275
DLPVC-200×3000 3150×200 3000 8800 3350x200x660 320
DLPVC-200×4000 4150×200 4000 9600 4350x200x760 430



How to work:

PVC PU Belt Hot Vulcanizing Press Air Bag



5. Other machines we can supply: more information pls freely to visit our website

PVC PU Belt Hot Vulcanizing Press Air Bag

PVC PU Belt Hot Vulcanizing Press Air Bag PVC PU Belt Hot Vulcanizing Press Air Bag

PVC PU Belt Hot Vulcanizing Press Air Bag

6. Packing:

PVC PU Belt Hot Vulcanizing Press Air Bag

7. Some shipping records, air shipment and sea shipment bill of ladings

 PVC PU Belt Hot Vulcanizing Press Air Bag

8. Working photos from customers

  PVC PU Belt Hot Vulcanizing Press Air Bag
