Home > Tools & Hardware > Hydraulic Parts > Hydraulic Cylinder > Festo Series Linear Guided Rod Cylinder

Festo Series Linear Guided Rod Cylinder

Festo Series Linear Guided Rod Cylinder photo-1
US$ 1 - 300 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Piston Cylinder
Power:
Pneumatic
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Standard or Nonstandard Standard
Structure Piston Cylinder
Power Pneumatic
Body Material Aluminum
Maximum Stroke 2000mm
Shaft Diameter 32, 40, 50, 63, 80, 100, 125
Place of Origin Zhejiang, China
Model Number LN Series
Brand Name Autoair Kunmanical

Festo Series Linear Guided Rod Cylinder

Festo Series Linear Guided  Rod Cylinder

1.Ordering Code

Festo Series Linear Guided Rod Cylinder2.Overall Dimensions

Festo Series Linear Guided Rod CylinderFesto Series Linear Guided Rod Cylinder



3.Detail Show

Festo Series Linear Guided Rod CylinderFesto Series Linear Guided Rod CylinderFesto Series Linear Guided Rod Cylinder

Festo Series Linear Guided Rod Cylinder

Festo Series Linear Guided Rod Cylinder

4.Why choose us
1: Various style for completely series pneumatic products for you to choose
2: High quality with competitive price
3: Sample order & small quantity order is ok
4: Provide free products information.
5. Reliable quality assured and active after-sell service

5.Payment and Shipment

Payment: T/T, Western Union, 30% deposit and 70% balance before shipping, LC, ;
Shipment: Usually we send the goods by DHL, FedEx, UPS, TNT, or EMS or as you require;
                    After we shipped your goods, we will send you the tracking number by E-mail.
                    If you do not receive it within 7 business days after shipping, please contact us.
Note:2: We do our best to ship your order in 2 week after receive your payment,and please allow 4-7 working days for the arrival of your shipment. Thank you !

8.Other Products

  Our company also can provide other pneumatic cylinders as below,
1. ISO Standard cylinder: DNC(ISO 6431&VDMA24562),DNG(ISO 15552),SI(ISO 6431),MA(ISO  6432)
2.Standard cylinder:SC/SU,MB,CA1
3.Mini cylinder:MA,MAL,CJ2,CM2,CJP Needle cylinder
4.Double-shaft cylinder:TN,CXS
5.Free installation cylinder:CU
6.Slide bearing cylinder:STM
7.Three-shaft cylinder:MGP
8.Stopper cylinder:RSQ
9.ADVU, SDA,CQ2B compact cylinder
10.Rotary cylinder:MSQ
11.Rodless cylinder:CY1
12.Air gripper:MHC Series Pneumatic Parrallel Gripper, MHC point type Gripper

      Parallel Style Wide Opening Air Gripper
