HR17 LV 3P 160A NH00 fuse link fuse switch disconnector

Specifications

1. Fuse link: NH00
2. 160A, 400V
3. 3P selected
4.CE, CCC, Rohs approved

Description:

DNH1(HR17) fuse switch disconnector is apply for the high short circuit current circuit with AC 50/60 HZ, voltage up to 660V and rated working current up to 1600A. It processes upper and lower end input and output structure. Lead in equipment with knife-edge and arc extinguishing equipment, and also can be operated with load. it is used as power switch, isolating switch and emergency switch, for protecting current.

Specification:



Model No.	HR17-40	HR17-100	DNH1-160	DNH1-250	DNH1-400	DNH1-630
Rated insulated voltage Ui	690V	690V	690V	690V	690V	690V
Rated working voltage Ue	380V	380V	380V	380V	380V	380V
Rated working current Ie	40A	100A	160A	250A	400A	630A
Rated short circuit connecting capacity Icm	400A	1000A	1600A	2500A	4000A	6300A
Rated limit short circuit current Inc	50KA	50KA	50KA	50KA	50KA	50KA
Used type	AC-23B	AC-23B	AC-23B	AC-23B	AC-23B	AC-23B
Matched fuse link	R016-40A	R017-100A	NT00-160A	NT1-250	NT2-400	NT3-630
