Open Type Diesel/Gasoline Water Pump With Electric Startup System

Name: Open Type Diesel/Gasoline Water Pump With Electric Startup System
Brand: Ruiying
SKU: 133454925

US$ 300 - 500 MOQ: 1 Set

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

Ruiying

Model Number:

80KB16-4(E)

Shanghai Ruiying Machinery Manufacture Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI CHINA

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name Ruiying

Model Number 80KB16-4(E)

Theory Rotary Pump

Structure Gear Pump

Usage Water

Power Hydraulic

Standard or Nonstandard Standard

Fuel Diesel

Pressure Low Pressure

Application Other, irrgation

Open Type Diesel/Gasoline Water Pump With Electric Startup System 80KB16-4(E)

Model Code		80KB16-4(E)
PUMP	Inlet and Discharge Port Diameter[mm/inch]	80(3")
	Rated Discharge (m³/h)	30
	Rated Lift (m)	13
	Self-Priming Time (s/4m)	120
	Max Suction Height (m)	8
ENGINE	Engine Model Code	RY178FE
	Rated Output Power[kW /HP]	3.7/5.0
	Rotation Speed (rpm)	3000
	Displacement (cc)	296
	Starting Method	Electric Start
	Fuel	Diesel
	Fuel Consumption (g/kW×h)	280
	Fuel tank capacity (L)	13.5
PACKING	Dimension (L×W×H) (mm)	570×480×665
	Packing size (L×W×H) (mm)	590×505×690
	Net weight (kg)	52
	In 20" Container (Sets)	180

Customer's Visiting

Company information

Package

Our Srevice

1.One year or 12 months warranty

from the day our customer get the machine, one year or 12 months, the first expired will be valid.

2.One Set Free Wearing Parts

One set wearing partswill be supplied for free,including air filter,oil filter,fuel filter.

3.After Sale Service

Any fault happens,please feel free to contact our after sale service department by:

Tel:0086-21-57581086,0086-21-57581618

FAQ

how long can I get the water pump

The max delivery time of our genset is 15 working days.
where do you send the water pump?

At present we have two factories, one in Shanghai and another is in Nanjing, we will arrange the delivery according to production schedule.
what about your warranty period.

our warranty period is one year or 1000 running hours, any problem during this time, you can contact us. we will offer after sale service.
what is your payment term

we prefer 30% deposit in advance, 70% before delivery. L/C is also acceptable.
