Type |
RY 3GF-LET-4 |
RY 5GF-LET |
lllumination |
||
Power×lamps quantity |
1000W×2 |
1000W×4 |
luminous flux |
220000Lm |
440000Lm |
Lamps |
Metal halide lamp |
|
Lamp post |
||
Lamp frame |
3section elevating frame |
|
Elevating height |
4300mm |
4500mm |
Elevating mode |
By hand-operated/By air-operated |
|
Anti-slope |
<10° |
|
Anti-wind level |
<6 |
|
Engine |
||
Mode |
RY178FE |
RY186FE |
Type |
Air cooled,4 stroke, single-cylinder
direct injection type diesel engine
|
|
Power |
4KW/5.5hp |
7.5KW/10hp |
Fuel tank volume |
13.5L |
|
Continuous working time |
8h |
8h |
Generator |
||
Type |
Single-phase alternator |
|
Frequency |
50/60Hz |
|
MAX Power |
3.1KVA |
5.5KVA |
Rated Power |
3KVA |
5.0KVA |
Insulation grade |
B |
|
Air compressor |
||
Power |
0.4kw |
|
Exhaust pressure |
0.7Mpa |
|
Displacement |
89L/min |
|
Dimension |
||
Transport size |
1700×810×2300mm |
1700×810×2450mm |
Packing size |
||
Main structure |
1700×810×1120mm |
|
Stanchion |
1900× 440×440mm |
|
Lamp and laterns |
580×1110×580mm |
580×1110×580mm |
Weight |
||
Weight |
313kg |
362kg |
MAX working weight |
325kg |
374kg |
Shanghai Ruiying Machinery Manufacture Co. Ltd has a factory in Shanghai and an new production base in Jiangsu province. Ruiying has been specilizing in producing of generator and diesel engine water pump.
The power of its generators are ranged from 2KVA to 2500kVA. Its generators mainly contain open type, soundproof type, wind and rain proof type, trailer type, intelligent type.
Flow of its water pump is from 10 m3/hr to 3400m3/hr. its water pump products is widely used for agriculture and industrial purpose.
1.Two year or 2000 hours warranty
From the day our customer get the machine, two year or 2000 hours, the first expired will be valid.
2. One set free wearing parts
One set wearing parts will be supplied for free, including air filter, oil filter, fuel filter.
3. After sale service
Any fault happens, please feel free to contact our after sale service department by:
Tel: 0086-21-57581086, 0086-21-57581618
1. How long can I get the generator
The max delivery time of our genset is 20 working days.
2. Where do you send the genset?
At present we have two factories, one in Shanghai and another is in Nanjing, we will arrange the delivery according to production schedule.
3. What about your warranty period.
our warranty period is two year or 2000 running hours, any problem during this time, you can contact us. we will offer after sale service.
4. What is your payment term
we prefer 30% deposit in advance, 70% before delivery. L/C is also acceptable.
