Product description
The teaching board is based on car starting system. It can fully display the composition and working process of the car starting system. The teaching of the composition and working principle of the starting system, fault-setting and fault diagnostics can be carried out. It is suitable for the theoretical study and practical operation of the starting system in the secondary vocational and higher vocational institutions.
Structure and composition
Starter, battery, neutral switch, high quality color schematic panel, fault-setting and troubleshooting system, control panel, removable stand, supporting manual and experiment guide book.
Features
1. It is based on the real car starting system.
2. The detection terminal is mounted on the teaching board. It can detect electrical signals, such as resistance, voltage, current, frequency, etc of the pin and the electrical components.
3. It has the specialized troubleshooting and set areas. You can set multiple common faults, stimulate the fault, test the fault and remove the fault.
4. The aluminum panel is painted with color high quality schematics.
Production technology
1. With locking casters to mobile devices. it can move freely, and facilitate teaching
2. Panel process: Aluminum panel with surface oxidation painting and UV Flatbed high true color schematic. It is durable and nice.
3. Detection terminals: 6mm stainless steel terminal
4. 6mmLED indicators
5. Dimensions: about 1260x850x1860mm
6. Maintenance intervals: 90 days
