Product description
The teaching board uses real car windows as the base. It can fully demonstrate the structure and work process of automotive power window system. The teaching of the electric window and the working principle and fault setting and diagnostic can be implemented. It is suitable for the secondary vocational and higher vocational institutions to have theoretical study and practice of automobile power windows.
Structure and composition
Control system of the power window, control switch, windows, battery, color schematic panel with computer handling, fault set and fault troubleshooting system, control panel, mobile stand.
Features
1. It is based on the real power window system and each system.
2. The detection terminal is mounted on the teaching board. The electrical signals can be measured, such as resistance, voltage, current, frequency, etc of the pin and the electrical components.
3. The panel is an aluminum panel. The color schematics after computer handling are elegant and durable. It is very convenient for students to analyses and to understand the work process of the power window.
4. It has multi-faults setting function.
5. After setting the fault, the participant can use the dedicated instrumentation to check out the location and content of the set point of failure through the fault troubleshooting exercises.
Production technology
1. Mobile stand with locking casters, you can move and lock the device easily.
2. Detection terminals: 8mm stainless steel terminals
3. 6mm LED indicator
4. Dimensions: about 1260x850x1890mm
5. Maintenance intervals: 90days
