Ceramic components for capillary thermostat
- 50 Piece / Pieces per Month
- Shenzhen
- Credit Card
Product Details
Place of Origin: | Hunan, China | Brand Name: | Jinghui | Model Number: | JH-TSC-xxx |
Type: | Insulating Ceramics | Material: | Alumina |
Packaging Details
Polybag with protective stuff
Product Description
Specifications
1. Made of steatite or alumina2.Famous of electrical performance and good resistent high tempreature
3.Meet RoHS and REACH
Product description:
1.Steatite or 95% alumina ceramic;
2.heat compression molding,the alumina has been to improved insulation and mechanical strength,heat resistance,performance, especially sensitivity to temperature.
3.The ceramics without crack, without burr,without pinholes,without gaps,without impurities, surface is smooth, dye absorption is passed;
4.The ceramic body is compact, Density ≥ 3.65g/cm3, high mechanical shock resistance.
5.Linear Dimension Tolerance ≤ ±0.015mm,Aperture Tolerance ≤ ± 0.02mm, Hole Deformation Size ≤ 0.01mm,Circumferential Deformation Size ≤ 0.1mm.
6.Insulation Resistance ≥ 100MΩ (have been checked by megohm in DC500V).
7.Dielectric Strength: AC2000V/50HZ/1min no breakdown phenomenon.
8.Linear expansion coefficient is slight,and less than 8.0 × 10-6mm /°C, and good for thermal shock performance.
9.Sintering temperature is 1700 °C, the use of a temperature not lower than 1300 °C, good corrosion resistance.
Application:
Widely used in different kinds of thermostat controller, Bimetal Disc Thermostat, oven Temperature Controller and so on.
v
Company Profile
Jinghui Industry Ltd. is a professional manufacturer specializing in the R&D, production of all kinds of alumina (AL2O3) ceramic, steatite ceramics,zirconia ceramic
part.
Founded in 2005 with factory in Xinhua of Hunan province, Our factory takes an area of 5000 square meters, and more than 100 experienced and skillful employees. We have won a lot of trust and good reputation from many famous customers around the world with our high quality products and professional services.Our factory mainly produces Al2O3 ceramic, steatite ceramic, zirconia ceramic series of ceramic products, It famous of these characters of resistance to high temperature, corrosion, abrasion and pressure. And they are widely used in the field of electronic, automobile, electric appliances, textile machinery, soldering, lighting, chemical industry, gas igniters, hydro-heating etc.
In the past few years, with our innovative & good quality products, competitive price and excellent customer service, we have supplied our products to more than 30 countries all over the world such as Europe, North & south America, Asia, Australia etc.
Based on our Xinhua factory, In order to serve to our customer better,we set up sales office at Shenzhen of Guangdong & HongKong as well.
With the company policy: Unity, Credible, Innovation , we continuously take in advanced technology at home and abroad, and strictly implement ISO9001:2000 quality management system in production, making many kind of stable and reliable products. We sincerely welcome all of the domestic and oversea customers to come to establish business with us, creating win-win business under reliable quality, competitive price and flexible delivery support.
