Good beo ceramic metallized ring for selling
| Product | Ceramic seal ring, ceramic seal face |
| Material used | 96% alumina , SiC, ZrO2 |
| Forming method | Hot pressing/ dry pressing/Iso-pressing |
| Color | White, black |
| Size capability |
Outer diameter and overall length
The max. OD can be up to 120mm. |
| Precision processing | Flat grinding; Cylinderical grinding |
| Key performance |
Flatness:≤0.0009mm; Perpendicularity:≤0.005mm; Parallelism:≤0.005mm; Roughness:≤0.4 No crack, no bubble, no scrach on surface |
| Features |
1.High mechansim strength and rigidity, 2.Excellent hardness and anti- chemical & aging-resistant, 3.Exceptional wear- resistance with low friction and self-lubrication, 4.Resistant high & low temperature, 5.Easy to protyping to mass production and cost& amp; nbsp;effective. |
| Quality inspection |
Fully inspection: visual & key dimensions every batch; Sampling inspection: regular dimensions and performance parameters |
| Lead time |
Custom made samples: 25~30 business days Volume production: 15~20 business days |
| Packing method |
Inner package: vacuum packing with; Outer package: Export carton; |
| Shipment port | Shenzhen port, Hongkong port |
| Application | Widely used as seal ring in varity of pump, centrifuge and compressor and so on. |
- Small part-size and large part size capability.
- Perfect metallized-seal strength and hermeticity.
- Consistent performance with all common braze alloys.
- Custom Metallized ceramic in aluminum oxide ceramics prototype to high volume production capacity.
Packaging: Vacuum packing with desiccant.
Delivery time: 15-25 days after order and samples are confirmed.
We, at Jinghui Industry Ltd, is a leading advanced ceramic components’ manufacturer in China who specilizing in producing various of fine ceramic components for different industry over than 10 years.
The selection manufacturing methods include dry pressing, hot pressing, isostatic pressing,extrusion, injection molding in selection of materials, also we have our own entire secondary precision processing and firing production line, such as lapping processing, CNC machining processing, metallization processing, laser cutting processing, glazing and firing processing and so on.
With our reliable products, professional service and good credit established with customers, we have been exporting our products to Europe, North American, Southeast, South American, South African more than 50 countries.
