Specifications
electric pallet truck1.Load capacity:1500kg
2.Fork height lowered 85MM
3.With CE certificate
Electric Pallet Truck Advantage
The philosophy of MAXIMIN Series is using minimal pallet truck to create maximal performance and efficiency, meanwhile save energy, save human force, save material, save your cost.
- Power
Use high quality assembly from industry's mature suppliers to ensure the funciton of the truck's power system and its stabilty.
1.Strong power, effort saving
Capacity 1.5 ton, reaching most customers' demands in goods transit.
Comparing to the hand pallet truck, more efficienct and covenient while lifting, lowering and walking.
2.Solid and durable
High quality assembly result in longer truck operation life
Solid body frame
- Delicacy
Reasonably removed unnecessary accessories to save materials and improve body frame intensity.
1.Beautiful appearance
Semi-enclose appearance design, brief and elegant.
2.Delicacy structure with excellent detail
Delicacy inner and outer struture design with excellent details.
3.Easy to maintenance
Modular produce, easy to dismantle and assemble 60AH Battery, free maintenance.
Mini Electric Pallet Truck
Ingenious designed, increase the space utilization
1.Small body , space saving
Small size makes passing in narrow pathway easily.
2.Agility and convenience in operation
Light body makes operation conveniently.
3.Ecnomic and energy saving
Cost efficient, origin design revolutionary truck in forklift industry
60AH Battery, energy saving and environment friendly
Electric Pallet Truck Specification
| Model | CBD15 | |
| Configuration No. | 610 | |
| Load capacity | kg | 1500 |
| load center | mm | 600 |
| Min.fork lowered height | mm | 85 |
| Max.fork lifring height | mm | 205 |
| Max.lifting height | mm | 120 |
| Overall fork width | mm | 540/600/685 |
| Fork length | mm | 1150/1200 |
| Fork width | mm | 160 |
| Fork thickness | mm | 44 |
| Overall length | mm | 1630 |
| Overall width | mm | 724 |
| Overall height(With handle) | mm | 1220 |
| Overall height(Without handle) | mm | 685 |
| Drive motor | kW | DC0.63 |
| Lift motor | kW | DC0.8 |
| Steering motor | kW | / |
| Battery voltage/capacity | V/Ah | 24/70 |
| Brake | ||
| Controller | CURTIS1243 | |
| Battery weight | kg | 48 |
| Service weight with battery | kg | 285 |
Packaging & Shipping
Our Services
At Shintool machinery, we supply ONE-STOP-SHOP solution service for warehouse equipments and Chinese brand forklift
parts.
Depends on 7 years experience and profession on the Chinese export business, any customer who have the business with us and also any other Chinese suppliers, we can be the position of supplying ONE-STOP-SHOP export service. Our nearest export
port is Shanghai, and Ningbo.We can be the main exporter who is in charger of connecting other suppliers, organizing the
shipment, LCL load, one B/L supply and other export issue service.
Electric Pallet Truck Warranty details
